7.2 CONNECTING THE HAND CONTROL

Insert the hand control in the RJ 45 hand control bushing (HC).

7.3 CASCADING

Cascading enables, through the connection of up to two controls, the operation of up to four synchronized
drives.
NOTICE
NOTICE

7.4 CONNECTING THE POWER SUPPLY

WARNING
NOTICE
USER MANUAL SMARTneo // PAGE 17
While plugging in the motor cables, you must observe the se-
quence M1 and M2 without fail.
It must be specified in advance via parameters whether a control
system is used for cascading. Minor deviations from the func-
tions of a single control are possible.
For additional information regarding the cascading, please refer
to the operating instructions for the cascading of motor controls.
Operating instructions are available in the download area of the
homepage www.logicdata.net
Check before you connect the power supply
Before you connect the power supply cable, check again:
• whether the mains voltage complies with the
rating plate of you control
• whether all components are connected to the
correct bushings. The motor control unit SMARTneo is
operational when the power supply cable is connected.
Depending on the parameterisation of the motor control unit
SMARTneo, a reset or a calibration run can be necessary after the
first connection of the power supply cable.
