- Page 1 User Manual Remote Control R13 ATEX Z2 Receiver www.danfoss.com...
- Page 2 User Manual R13 ATEX Z2 Receiver Revision history Table of revisions Date Changed July 2024 Updated installation information 0201 January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | July 2024 BC292458486592en-000201...
-
Page 3: Table Of Contents
User Manual R13 ATEX Z2 Receiver Contents Safety instructions FCC rules......................................4 General safety....................................4 Safety warnings....................................5 Technical description Dimensions......................................6 Hardware description..................................7 Installation Receiver installation..................................8 Troubleshooting R13 ATEX Z2 troubleshooting..............................9 © Danfoss | July 2024 BC292458486592en-000201 | 3... -
Page 4: Safety Instructions
The following safety instructions must be read carefully to install and use the product properly, and to keep it in perfect working condition, and to reduce the risk of miss use. • Danfoss recommends the use of ESD PPEs (electrostactic discharge personal protection equipment). •... -
Page 5: Safety Warnings
Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. Quick reference precautions © Danfoss | July 2024... -
Page 6: Technical Description
User Manual R13 ATEX Z2 Receiver Technical description R13 x dimensions Dimensions in mm 232.00 84.87 216.00 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 81.55 60.69 219.73 37.50 248.93 Fixing slots (fixed assembly or anti-vibration) M32 cable gland ©... -
Page 7: Hardware Description
R13 ATEX Z2 hardware description Multi-band antenna Power supply Internal EEPROM Signaling LEDs TR800-CE MCX radio Wiring communication R13 ATEX Z2 receiver only allows Altern Current (AC) power supply and a maximum of 13 relays. © Danfoss | July 2024 BC292458486592en-000201 | 7... -
Page 8: Installation
User Manual R13 ATEX Z2 Receiver Installation R13 ATEX Z2 receiver installation The below information describes hazards to be aware of during installation and steps to locate the receiver. Risk of shock Completely shut down the machine when installing the receiver. -
Page 9: Troubleshooting
No radio signal detected LED on + transmitter switched Radio channel occupied Change transmitter's frequency channel LED on + DATA switched off Radio channel occupied by non Danfoss system Change transmitter's frequency channel DATA LED off + SINGAL LED on Radio error Replace radio Green;... - Page 10 Phone: +86 21 2080 6201 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
