• Contact your energy supplier to check which energy plan you are on,
and whether the off peak times change during winter and summer.
• On the tariff table (located on the reverse of the front panel), find which
program collates with your energy plan. Using a terminal screwdriver, turn
the program selector to the correct number for the program (if you want
a program that is not shown on the table, select the closest one to your
desired program and this can be adjusted later).
• On the back of the unit select GMT ONLY or GMT/BST depending
on your energy plan;
• GMT ONLY fixes the time to GMT.
• GMT/BST sets GMT over the winter period, and GMT+1 over the
summer period.
Winter and Summer are displayed according to daylight saving periods
regardless of the switch position.
6
• Ensure all terminals are secured and screw the front panel of the unit
to the back box using the 2 fixing screws previously removed.
Operating Modes
• OFF: With the rocker switch set to
OFF, there is no output regardless
of the program or boost. The unit
can still be programmed and the
internal battery will charge.
• TIMED: With the rocker switch
set to TIMED, the output will
be according to the program,
or the appropriate boost period.
Auto will be displayed on the
screen in this mode.
