1. General Information

These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the
thermostat is switched off and the circuit supply fuses are removed
or the circuit breaker turned off.
• It is recommended that a quali ed electrician is consulted or used for the
installation of this thermostat and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this thermostat is
tted does not exceed the rating of the circuit cable, fuse or circuit breaker.
• To clean use a clean dry cloth only. Do not use any liquid cleaners.

3. Technical Specifications

Receiver
1
• 230V AC 50 Hz
• This thermostat is of Class ll Construction and must not be earthed
• Switch Rating:
• Switch Type:
• Connection Type:
• Micro Disconnection:
• Illumination:
• Output Light:
• Installation Type:
• CE Compliant
• Dimensions (H x W x D):
3(1)A
Single pole, voltage free
changeover contacts
3 wire
Type 1.B control action
Blue LED illuminated on setting
for button surrounds
Red LED
Surface mount with wall plate
90 x 95 x 30mm
