Transmitter
• Batteries:
• Operating Temperature Range: 0°C to +40°C
• Set Temperature Range:
• Temperature Swing Adjuster: +/- 0.5°C or 1.0°C set by DIP switch
• PID Adjustment:
• Boiler Type Adjustment:
• Frost Protection Mode:
• Night Set Back Mode:
• Transmission:
• Illumination:
• Installation Type:
• CE Compliant
• Dimensions (H x W x D):
Transmitter Front View
2
Digital room temperature display
(illuminated on setting)
10°C to 30°C
set temperature
range
The heating symbol
will show when heat
is demanded
2x 1.5V AA
10°C to 30°C
ON or OFF set by DIP switch
3CYC = Gas, 6CYC = Oil, set by DIP switch
5°C
Lowers set temperature
by 4°C for 1-9 hours
868.3MHz
Blue LED illuminated on setting
for button surrounds and display
Surface mount with wall plate
90 x 95 x 30mm
Night set-back (reduces temperature
by 4°C, 1-9 hours recall) and frost
Flip down cover for display battery
compartment and reset button –
uses 2x 1.5V AA batteries supplied
protection setting mode
+/- setting
buttons
(illuminated
on setting)
