1. General Information
These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the
Programmer is switched off and the circuit supply fuses are removed
or the circuit breaker turned off.
• It is recommended that a quali ed electrician is consulted or used for the
installation of this Programmer and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this Programmer is
tted does not exceed the rating of the circuit cable, fuse or circuit breaker.
• To clean use a clean dry cloth only. Do not use any liquid cleaners.
3. Technical Specifications
• 230V AC 50 Hz
1
• This thermostat is of Class ll Construction and must not be earthed
• Switch Rating:
• Switch Type:
• Connection Type:
• Installation Type:
• Micro Disconnection:
• Operating Temperature Range: 0°C to +40°C
• Programme:
• Pumped or Gravity Operation: System P or System G set by DIP switches
• Time Control Periods:
• Clock Format:
• Summer/Winter Changeover: Day light saving, GMT or BST
• Holiday Mode:
• Boost Function:
3(1)A
Single pole, double throw (SPDT)
for both heating and hot water,
change over contacts
3 wire
Surface mount with wall plate
Type 1.B control action
5 day plus 2, or 7 day set by DIP switches
3 per day with copy function
12 hour AM/PM or 24 hour
0 to 31 day program suspension
1, 2 or 3 hour for both heating
and hot water
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the TRT036N and is the answer not in the manual?
Questions and answers
have not been able to set time despite following all instructions
To set the time on a Timeguard TRT036N:
1. Press and hold the Select button for 3 seconds to begin setting the clock.
2. The 12-hour symbol will be displayed.
3. Use the arrow buttons to switch between 12-hour and 24-hour formats.
4. Press the Select button to move to setting the hour (the hour will blink).
5. Use the arrow buttons to adjust the hour to your local time.
6. Press the Select button to move to setting the minutes (the minutes will blink).
7. Use the arrow buttons to adjust the minutes.
8. Press the Select button to move to setting the year.
9. Use the arrow buttons to set the correct year.
10. Press the Select button to move to setting the month.
11. Use the arrow buttons to set the correct month.
12. Press the Select button to move to setting the day.
13. Use the arrow buttons to set the correct day.
Once all settings are adjusted, the clock will be set.
