1. General Information
These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the
thermostat is switched off and the circuit supply fuses are removed
or the circuit breaker turned off.
• It is recommended that a qualified electrician is consulted or used for the
installation of this thermostat and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this thermostat is
fitted does not exceed the rating of the circuit cable, fuse or circuit breaker.
• To clean use a clean dry cloth only. Do not use any liquid cleaners.
3. Technical Specifications
• 230V AC 50 Hz
1
• This thermostat is of Class ll Construction and must not be earthed
• Switch Rating:
• Switch Type:
• Connection Type:
• Installation Type:
• Micro Disconnection:
• Operating Temperature Range: 0°C to +40°C
• Set Temperature Range:
• Temperature Swing Adjuster: +/- 0.5°C or 1.0°C set by DIP switch
• Frost Protection Mode:
• Night Set Back Mode:
• PID Adjustment:
3(1)A
Single pole, voltage free changeover
contacts
2 wire
Surface mount with wall plate
Type 1.B control action
10°C to 30°C
5°C
Lowers set temperature by
4°C for 1-9 hours
ON or OFF set by DIP switch
