PLUSOPTIX S12C Short Manual page 4

3 Downloading the software update directly onto the Plusoptix
Vision Screener (LAN/WLAN or Mini-USB)
If you want to download the software update using LAN/WLAN or Mini-USB, take the
following precautions for updating the software:
- Insert an empty SD card (plusoptiX 12) or USB stick (plusoptiX 16)
- Connect the Plusoptix device to the power network
- Establish internet access (either over a LAN/WLAN-connection or over a Mini-USB cable
to your workplace computer)
- Touch the button to configure the software (1) in the settings.
- Then touch the button (2) to download the latest software
- Confirm with the green checkmark (3). You will be guided through the download (see
figure 2).
When downloading, the software update will be saved on the SD card or USB stick and a
confirmation will be displayed. As soon as you touch OK, the Plusoptix Vision Screener will
automatically restart and install the software update saved on the SD card or USB stick.
Figure 1: Downloading software updates
1) 2)
Seite 4 von 6
3)
