6. INSTALLING THE MOUNTING BRACKET

REMEMBER to disconnect the power by removing fuses or turning off circuit breakers.
Follow the steps below to hang your fan properly:
1. Disconnect power to the fan location. A licensed electrician must
install the fan if required by your local electrical code (Fig. 5).
2. Remove 1 of 2 screws from the bottom of the mounting bracket
and loosen the other screws.
3. Pass the 120-volt supply wires through the center hole in the
ceiling mounting bracket as shown in Figure 7.
4. Secure the mounting bracket to the ceiling outlet box with the
screws and flat washers provided (Fig. 7).
FR - W 1 8 10
FIGURE 5
FIGURE 6
UL/cUL Listed
electrical box
Mounting
bracket
Mounting screws
FIGURE 7
Mounting
bracket
Screw
120V wire
