4. PACKAGE CONTENTS

REF.
A
B
C
D
E
F
G
H
I
3/16" x 6mm Philips/ Slotted screws (13 pcs) - Blade Collector Ring
1/4" x 11mm Philips/ Slotted flat head screws (7 pcs) - Blade Screws
#8-32x38mm Pan Head Philips Screw (2) - Hanger Bracket
Φ 5.2x8.4x1mm Spring washers (2) - OPTIONAL for direct wood mount - Hanger Bracket
Φ 4.4x9.4x1mm Star washers (2) OPTIONAL for direct wood mount - Hanger Bracket
#10x38mm Pan head Philips wood screws (2) - OPTIONAL for direct wood mount - Hanger Bracket
#10x76mm Pan head Philips wood screw (1) -Safety Cable
NOTE: ** denotes finish code of fan
FR -W 1 8 1 0
DESCRIPTION
Blade Set of 3
Hanger Assembly
- Mounting Bracket
- Downrod Assembly
Canopy w/ Trim Canopy Ring
Coupling Cover
Motor Assembly
Control Receiver w/ hardware
Wall Control w/ Hardware
Blade Collector Ring
Hardware Bag
Φ 5x14x1mm Flat washers (2) - Hanger Bracket
Φ 5.2x8.4x1mm Spring washer (1) - Safety Cable
Φ 6.5x19x2mm Flat washer (1) - Safety Cable
Unpack your fan and check the contents.
You should have the following items:
PART NO.
RPL-F1810-60-BD-**
RPL-HGR-ASM-**
---
RPL-CAN-RND-**
RPL-COU-CVR-**
---
RPL-F1810-60-REC
F-WC-WT
---
RPL-VORTEX-PARTS
