7. ASSEMBLING THE FAN BLADES

1.
Assemble the three blades together using the blade collector ring
and the screws provided (Fig. 8 & 9).

8. ATTACHING THE MOTOR

1.
Attach blade assembly to the motor assembly as shown with
provided blade screws (Fig. 10).
FR -W 1 8 1 0
FIGURE 8
FIGURE 10
FIGURE 9
10
