Source Four Mini LED

Track Installation Procedure

WARNING:
A V E R T I R :
Step 1: Insert the track adapter into the
track. The adapter will only fit one
way into the track with the tabs of
the adapter in the groove of the
track.
Step 2: Lock the adapter into place.
Step 3: Select circuit 1 or 2 using the
circuit selection wheel.
The 230V track adapter has a three-
circuit selector knob.

Step 4: Focus the fixture.

Step 5: Lock the fixture into place using the yoke lock.
There are cable protection posts
on both the yoke lock and the
yoke that prevent the fixture from
rotating a full 360°.
The yoke can be locked into
place using a 1.5mm Allen
wrench.
Can op y an d T ra ck Mo unt Kit s
To reduce the risk of fire and electric shock, use only with
EUTRAC track system.
Réduire le risque de feu et la décharge électrique, l'usage
seulement avec le systéme de piste d'EUTRAC.
Pa ge 4 o f 4
Tabs
Circuit selection
wheel
Lock
