USER MANUAL
This document is property of SENECA srl. Duplication and reprodution are forbidden, if not authorized. Contents of the present documentation refers to
products and technologies described in it. All technical data contained in the document may be modified without prior notice Content of this
documentation is subject to periodical revision.
To use the product safely and effectively, read carefully the following instructions before use. The product must be used only for the use for which it was
designed and built. Any other use must be considered with full responsibility of the user. The installation, programmation and set-up is allowed only for
authorized operators; these ones must be people physically and intellectually suitable. Set up must be performed only after a correct installation and the
user must perform every operation described in the installation manual carefully. Seneca is not considered liable of failure, breakdown, accident caused for
ignorance or failure to apply the indicated requirements. Seneca is not considered liable of any unauthorized changes. Seneca reserves the right to modify
the device, for any commercial or construction requirements, without the obligation to promptly update the reference manuals.
No liability for the contents of this documents can be accepted. Use the concepts, examples and other content at your own risk. There may be errors and
inaccuracies in this document, that may of course be damaging to your system. Proceed with caution, and although this is highly unlikely, the author(s) do
not take any responsibility for that. Technical features subject to change without notice.
Z-PASS1
Z-PASS2
SENECA s.r.l.
Via Austria, 26 – 35127 – Z.I. CAMIN – PADOVA – ITALY
Tel. +39.049.8705359 – 8705408 Fax. +39.049.8706287
Web site:
www.seneca.it
Support:
supporto@seneca.it
Sales:
commerciale@seneca.it
MI003800_112
(IT),
support@seneca.it
(IT),
sales@seneca.it
Page 1
(Other)
(Other)
