3 analog outputs module with RS485
3 analog outputs module with RS485
serial interface MODBUS RTU protocol
serial interface MODBUS RTU protocol
Installation
Installation
Manual
Manual
Contenuti:
- General specifications
- Technical specifications
- Modbus connection rules
- Installation rules
- Electrical connections
- DIP-switches settings
- Analog outputs
- Frontal panel LEDs signallings
- Default conditions
- Module layout
- Decommissioning and disposal
SENECA s.r.l.
Via Austria, 26 – 35127 – PADOVA – ITALY
Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287
For manuals and configuration software please see: www.seneca.it
This document is property of SENECA srl. Duplication and reproduction are forbidden (though partial), if
not authorized. Contents of the present documentation refers to products and technologies described in
it. All technical data contained in the document may be modified without prior notice.
Content of this documentation is subject to periodical revision
Z-3AO
Z-3AO
.
MI000758-E
ITALIANO 1/8
