Error Codes - Electrolux EFME617SIW Service Manual

Diagnostic System (For Models 617, 517 and 417 Series)

16.8 Error Codes

Code Full Name
Door Opened at Cycle
41
Start
42 Door Open Sensing Error
51 Drum Motor Relay Error
Drum Motor Start Sensing
52
Error
Drum Motor Centrifugal
53
Switch Error
54 Drum Motor Sensing Error
61 Heater Relay Error
63 Heater Short Error
64 Heater Open Error
65 Thermostat Open
67 Heater Sensing Error
71 NTC1 Error
72 NTC1 Error
73 NTC2 Error
74 NTC2 Error
Notes and Possible Causes
Door open
Door Lock or Wiring or Sensing Circuit on Main
Board Failure.
With Line Safe Relay closed, motor sensing detects
voltage on motor.
1. Motor Short Circuit to ground (Motor or Wiring)
2. Electrical Noise
3. Line Safe Relay Problem (Main Board Failure)
4. Motor Relay open or short
Motor Relay driven but start sensing not congruent.
1. Motor Fault
2. Main Board Fault
Motor driven but sensing not congruent.
1. Motor Fault
2. Main Board Fault
Drum Motor Relay Sensing Circuit Failure (Main
Board Failure)
1. Heater Disconnected (Wiring or Connector
Failure)
2. Heater Failure
3. Heater Relay Failure (Open Circuit)
Heater Sensing Circuit Failure (Main Board Failure)
Heater Failure
Heater Sensing Circuit Failure (Main Board Failure)
Heater Failure
Heater Thermostat Trip
Heater Sensing Circuit Failure (Main Board Failure)
NTC Open / Disconnected or Main Board Fault
NTC Short or Main Board Fault
NTC Open / Disconnected or Main Board Fault
NTC Short or Main Board Fault
42
User
Page
Interface
No.
Notification
No 44
No 44
No 45
No 46
No 48
No 48
No 49
No 49
No 49
No 50
No 51
No 51
No 51
No 52
No 52
