WisyCom MSR916 User Manual page 8

 Bar-graph meters
 Led indications
 Powering
 Size
 Weight
Note [1]: RMS value, unweighted, 22 Hz / 22 kHz, and referred to the peak deviation.
7
 RF field strengths (both "A" and "B" antennas at the same time )
:
 AF output level (-20 ÷ +12 dBu).
 TX battery lifetime, 5 steps: 100%, 75%, 50%, 25%, 12% (the last Led blinks ).
 diversity switching ("A" / "B" antenna)
:
 AF output-line is active (AF ON)
 matching sub-carrier is present (P.TONE)
 channel Group 1 selected (#1)
 tone-squelch function is on (T.SQL)
 receiver on.
 10.5 ÷ 16 Vdc / 4 W (typ.: 350 mA @ 12 Vdc), negative ground
:
 mains 100 ÷ 240 Vac, by means of separated PSP910-X4 "mains-plug" power
supply.
:
240,99 x 225,2 x 43,6 mm (WxDxH)
:
1.7 Kg approx.
