INSTALLATION INSTRUCTIONS
EQUILITY
™
(Formerly LYNDON
)
®
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions
carefully before you begin. (Certain installations may require professional help.) Also be sure your
installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
ATTENTION INSTALLER:
Please deliver this manual to homeowner.
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2018
5-1/2' x 30"
(1676 x 768 mm)
5-1/2' x 33"
(1676 x 838 mm)
- 1 -
MODEL D12536-004
MODEL D12536-014
754988-100 Rev. D (5/18)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DXV EQUILITY D12536-004
Summary of Contents for DXV EQUILITY D12536-004
-
Page 1: Installation Instructions
MODEL D12536-014 (1676 x 838 mm) Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes. - Page 2 TABLE OF CONTENTS: Cover....................Page 1 Table of Contents .................Page 2 Safety Instructions Notice ..............Page 3 General Installation Information ............Page 4 Tub Specifications ................Page 5 Roughing-in Reference .................Page 6 Freestanding Tubs ................Page 7 Post Installation Instructions ..............Page 8 754988-100 Rev. D (5/18) - 2 -...
-
Page 3: Important Safety Instructions
If you are or think you may be pregnant, consult your physician before using the bathtub. Use this unit only for its intended use as described in this manual. Do not use any attachments not recommended by DXV. SAVE THESE INSTRUCTIONS 754988-100 Rev. -
Page 4: General Installation Information
4. If any leaks or operating problems are discovered, do not complete installation until problems are resolved. DXV will not be responsible for any costs involved with removing or reinstalling the tub, or for the costs of any surrounding materials or labor. - Page 5 (1527 x 692 mm) 57 lbs./ft² (55 kg.) (250 l.) D12536-014 (279 kgs/m²) For more details, see specification page per model at www.dxv.com The drain outlet is directly under the drain hole in the tub. 754988-100 Rev. D (5/18) - 5 -...
- Page 6 INSTALLATION INSTRUCTIONS: • Place the tub on a finished, level floor in the desired location. ª Using an erasable pencil or marker, trace the outline of the base of the tub on the floor. (See Fig. 1) FIG. 1 • Using the adjustable feet on the underside of the tub, ensure that the tub is level.
- Page 7 • Apply a generous bead of silicone caulking to the base of the tub. (See Fig. 5) FIG. 5 • Carefully set the tub into position. Ensure that drain tail piece gasket is fully seated against the tail piece flange. •...
- Page 8 Ecatepec, Estado de México 55540 Canada For residents of the United States, warranty Toll Free: 01-800-8391200 information may also be obtained by calling Toll Free: 1-800-387-0369 www.DXV.mx the following toll free number: (800) 227-2734 Local: 905-306-1093 www.DXV.com Fax: 1-800-395-1498 www.DXV.ca 754988-100 Rev.
