INSTALLATION INSTRUCTIONS
Single Lever Faucet
Rem
®
Monoblock
Model D3510010C
Monoblock Vessel
Model D3510015C
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Tubing Cutter
ROUGHING-IN DIMENSIONS:
• For reference
1-1/2"
(38 mm)
11-7/8"
(302 mm)
8-1/4"
(210 mm)
MOUNTING
SURFACE
2"
2-7/16"
(51 mm)
(65 mm)
20"
(508 mm)
3/8" (10mm)
SUPPLIES
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Channel Locks
Plumbers' Putty or Caulking
(289 mm)
6"
(152 mm)
MOUNTING
SURFACE
1-3/16" MAX. (30 mm)
5/8" MIN. (15 mm)
2" MAX.
(51mm)
10" MAX.
1-1/4" O.D.
(254 mm)
NOTE: MOUNTING HOLE 1-3/8" DIA. (35 mm)
Phillips Screwdriver
Flat Blade Screwdriver
1-1/2"
(38 mm)
11-3/8"
MOUNTING
SURFACE
2"
(51 mm)
20"
(508 mm)
(32 mm)
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
Basin Wrench
Adjustable Wrench
5-3/4"
(146 mm)
7-1/8"
(181 mm)
3-1/2"
(89 mm)
2-7/16"
1-3/16" MAX. (30 mm)
(65 mm)
5/8" MIN. (15 mm)
3/8" (10 mm)
SUPPLIES
10" MAX.
(254 mm)
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
M965700 Rev. 1.1 (4/17)
6-3/4"
(171 mm)
2" MAX.
(51 mm)
1-1/4" O.D.
(32 mm)
