Outdoor Electric/Motorized Projector Screen
Thank you for choosing the Twilight Electric projection screen! Please read through this user guide
before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Product Description:
The Twilight Electric is an outdoor projector screen for wall and patio installations that brings media
room quality to your outdoor spaces. Its sleek aluminum casing beautifully accessorizes your
backyard, patio, pool deck or anywhere a gathering for evening movie time is appropriate.
Outdoor Projection Screen Disclaimer
Never leave your projection screen out and exposed to direct sunlight. Regardless of screen brand,
prolonged exposure to the sun's ultraviolet radiation degrades the chemical bonds causing the
material to eventually decompose. Photo degradation first causes the material to lose its theater-
grade reflective qualities. Eventually nature will destroy even synthetic materials. For this reason,
the Twilight Electric has a retractable design that allows the material to be drawn up into its
protective casing to be shielded from solar radiation.
Care & Use Instructions
Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of
the points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the
screen material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents
or alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to
clean it.
To avoid damage and injury, the screen should only be operated by adults.
Rev.JA05302018
Twilight Electric Series
User's Guide
1
www.epvscreens.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Twilight Electric Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EPV Twilight Electric Series

  • Page 1 Twilight Electric Series Outdoor Electric/Motorized Projector Screen User’s Guide Thank you for choosing the Twilight Electric projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life. Product Description: The Twilight Electric is an outdoor projector screen for wall and patio installations that brings media room quality to your outdoor spaces.
  • Page 2 Understanding the Ingress Protection Rating IP33 Important Safety & Warning Precautions Make sure to read this user’s guide and follow the procedures below. • Please retain this user’s guide for future reference. • To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the manufacturer.
  • Page 3 The installer must insure that the fasteners used are of adequate strength and suitable for the installation location. Hardware Parts List for Twilight Electric Series E. M5x15 Screw&...
  • Page 4 Flush Mount to the Wall 1. Mark the location of where the screen is to be installed, drill your holes and insert the M10Anchors (B). 2. Install the Mounting Brackets (A) to the wall and secure with the M4x50 Screws (B). Mounting Bracket Mounting bracket Fix Plate 1...
  • Page 5 Flush Mount to the Ceiling Note: Please make sure the Mounting Bracket (A) is close to the wall when you install the screen on the ceiling. This is to ensure the weight bar aligns with the magnetic bottom bracket when it comes down. 1.
  • Page 6 B. Wireless 12-volt projector trigger, ZOMS-TR12Vx1pc Screen operation Electric Current: Depending upon region, your EPV Screen will operation 100v, 110v, or 220v voltage. 1. After ensuring the power outlet & screen are compatible (voltage), plug the power cord into the power outlet.
  • Page 7 Note: The beep(s) the screen produces are very faint. It may be difficult to hear, if more than 5 feet away from the screen. 2. Wireless 12 volt trigger (Item B): The ZOMS-TR12V is a wireless 12-volt projector trigger that synchronizes to your projector’s power cycle for easy operation.
  • Page 8 Magnetic bottom bracket Installation 1. After the screen is plugged in to a power outlet, press the DOWN button on the RF remote control (F). Install the magnetic bottom bracket (G) so that the weight bar sleeve cradles inside (see picture below). Note: The screen should deploy straight down and align with the magnetic bottom bracket (G).
  • Page 9 Curved Stake (H) to secure screen to the ground and supply adequate tension to the screen. Carabiner Iron Ring Elastic String Curved Ground Stake For more information, technical support or your local EPV Screens contact, www.epvscreens.com please visit Rev.JA05302018 www.epvscreens.com...
