Instruction
22
APP pump instruction APP 11-13 and APP 16-22
APP 11 - APP 13
Description APP 11 - APP 13
Parallel key, mm 10 × 8 × 45
DIN 6885
inch 0.39 × 0.31 × 1.77
Bleeding G ¼", Hexagon AF = 6 mm
Inlet port M42 x 1.5; depth 17 mm
Outlet port M42 x 1.5; depth 17 mm
Pump mounting 125 B 4
flange
APP 16 – APP 22
Description APP 16 – APP 22
Parallel key, mm 12 × 8 × 70
DIN 6885
In 0.47 × 0.31 × 2.76
Bleeding G ¼", Hexagon AF = 6 mm
Inlet port M52 x 1.5; depth 21 mm
Outlet port M52 x 1.5; depth 21 mm
Pump mounting 125 B 4
flange
180R9265 / IOM APP 16-22 Appendices - v02 / 01.2013
Accessories Type
2" Victaulic
2" inlet hose kit
2 m / 79"
2" inlet Vic. 2" Victaulic
Super Duplex
Non-return 1,5" Victaulic
valve (outlet)
(OD 48,3 mm)
Super Duplex
For more details on the accessories, please
contact the Danfoss RO Solutions Sales
Organisation.
Accessories Type
2" inlet hose 2" Victaulic
kit 2 m/79"
2" inlet Vic. 2" Victaulic
Super Duplex
Non-return 2" Victaulic
valve (outlet)
(OD 63 mm)
Super Duplex
For more details on the accessories, please
contact the Danfoss RO Solutions Sales
Organisation.
Code no.
180Z0298
180Z0166
180H0053
Code no.
180Z0298
180Z0165
180H0256
