4.5.1 Probe Info

If this menu item is selected, various information of the probe is called up and displayed.

4.5.2 Material Calibration

The menu item „Material Calibration"enables to adjust a material-specific calibration stored in
the probe. This enables to significantly increase the accuracy of the measurement. There are
up to 15 material-specific calibrations deposited in the firmware of a SONO probe. These are
presented here and can be selected with the buttons
a calibration hereby points out the current standard calibration. Store the selected calibration
as standard in the probe using the button . The set calibration will subsequently be stored in
the non-volatile memory of the probe. The menu item "Material calibration" is exited by
actuating the button .

4.5.3 Offset Balancing

In order to compensate measurement errors e.g. due to density deviations in the material or
due to the installation conditions, there is an option to perform a linear displacement of the
measurement value. This is the purpose of this menu item. It is possible to displace the
measurement value between -10 and +10 percent points. The set displacement is stored in
the probe and will subsequently also affect the analogue output. The setting is maintained in
a traceable manner.

4.5.4 Averaging Mode

This menu item enables the activation, respectively the changing of a measurement value
establishment in the probe. IMKO moisture probes respectively offers the following options:
Mode CS: (cyclic-successive) Without averaging function intended for very short measuring
processes in a range limited to seconds (e.g. 5...20 seconds) at which up to 100
measurements are performed internally per second at a cycle time of 250 milliseconds at the
Page 14
Manual SONO-VIEW Version 3_1
You can exit the menu item „Probe Info" with the button
.
Adjust the offset to the desired value using the buttons
/ . Subsequently store the set value in the probe
with the button . You can exit this menu item with the
button .
. The character „1" set in front of
/
2017-05-24
