OPERATION
S I
ET THE NCUBATOR
SMI12: Each incubator must be set independently.
1. Set the OTL control to its maximum setting, if not already set to max.
•
2.
Jump to the Temperature Set Point Adjustment mode
Set Temperature
Set Point Adjustment Mode
Press and
Note: The display will automatically exit the adjustment mode after 5
hold either
seconds of inactivity on the arrow keys, saving the last shown set point
value.
3.
Set the Temperature Set Point
New Set Point
Adjust
4.
Wait for 5 seconds after entering the Set Point
Set Temperature
The display will stop flashing. The set point is now saved in the controller.
•
The display will revert to showing the current chamber air temperature,
•
heating or passively cooling to match the new set point.
See the next page for how to set the Over Temperature Limit heating cutoff.
T
EMPERATURE
Turning the OTL all the way to the right (clockwise) prevents the heating
cutoff system from interfering with setting a higher temperature.
End of procedure
S P
ET OINT
Set Temperature
Initial Set Poiint
Note: To turn an incubator off, set the set
point to its lowest setting (OFF).
HEATING ACTIVATED
