INSTALLATION
R A
EQUIRED MBIENT
These units are intended for use indoors, at room temperatures between 15°C and 30°C (59°F and 86°F),
at no greater than 80% Relative Humidity (at 25°C / 77°F).
Operating these units outside of these conditions may adversely affect its incubator temperature stability
and effective operating range. For conditions outside of those listed above, please contact your SHEL LAB
distributor to explore other options suited to your laboratory or production environment.
R C
EQUIRED LEARANCES
These clearances are required to provide air flows for ventilation and cooling.
Power Cord
2" (51mm)
4" (102mm)
4 inches (102mm) of clearance is required on the sides and back.
2 inches (51mm) of headspace clearance between the top of the unit and any overhead partitions.
E
NVIRONMENTAL
Consider proximate environmental factors that can affect the chamber temperature and atmospheric
integrity when selecting a location to install the unit:
Ovens, autoclaves, and any device that produces significant radiant heat
•
High-traffic areas
•
Direct sunlight
•
Heating and cooling ducts, or other sources of fast-moving air currents
•
10 | P a g e
C
ONDITIONS
4" (102mm) 4" (102mm)
D S
ISRUPTION OURCES
2" (51mm)
Door Swing
SMI7 30" (762mm)
All Other SMIs 26" (660mm)
