- Page 1 AIR-JACKETED CO INCUBATOR 110 – 120 Volts Installation - Operation Manual SCO10A SCO5A...
- Page 2 Pictured on the front cover, left to right: SCO10A, SCO5A Note: The SCO10A requires two power outlets. W arning: This product contains chemicals, including triglycidyl isocyanurate, known to the State of 4 8 T 4 8 T California to cause cancer as well as birth defects or other reproductive harm. For more information, go to w ww.P65Warnings.ca.gov...
- Page 3 INCUBATORS 110 – 120 Voltage Part Number (Manual): 4861730 Revision: April 19, 2020 SHEL LAB is a brand of Sheldon Manufacturing, INC, an ISO 9001 certified manufacturer. Safety Certifications These units are TÜV CUE listed as air-jacketed CO Incubators for professional, industrial, or educational use where the preparation or testing of materials is done at an ambient air pressure range of 22.14 –...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................................. 7 Read this Manual ..................................7 Safety Considerations and Requirements ........................7 Contacting Assistance ................................8 Manufacturing Warranty ..............................8 Engineering Improvements..............................8 Gas Supply ..................................9 Reference Sensor Devices ..............................10 RECEIVING YOUR UNIT ............................11 Inspect the Shipment ................................ - Page 5 UNIT SPECIFICATIONS ............................55 Weight ..................................... 55 Dimensions .................................... 55 Max Shelves For Unit ................................. 56 Capacity ....................................56 ......................................56 Temperature ..................................56 Power ...................................... 56 PARTS LIST ................................57 Accessories ................................... 58 Ordering ....................................58 P a g e...
- Page 6 TABLE OF CONTENTS P a g e...
-
Page 7: Introduction
INTRODUCTION Thank you for purchasing a SHEL LAB incubator. We know you have many choices in today’s competitive marketplace when it comes to constant temperature equipment. We appreciate you choosing ours. We stand behind our products and will be here if you need us. -
Page 8: Contacting Assistance
Therefore, some changes, modifications, and improvements may not be covered in this manual. If your unit’s operating characteristics or appearance differs from those described in this manual, please contact your SHEL LAB dealer or customer service representative for assistance. -
Page 9: Co 2 Gas Supply
INTRODUCTION Note: A CO gas regulator must be purchased separately from the incubator. Note: Each incubation chamber in an SCO10A must have its own CO supply. UPPLY Supply Required The incubator must be connected to a carbon dioxide gas supply system in order to establish and maintain a CO -enriched incubation chamber atmosphere. -
Page 10: Reference Sensor Devices
INTRODUCTION EFERENCE ENSOR EVICES Must be purchased separately Reference sensor devices or a combined device are required for calibrating the incubator temperature and CO displays. Reference devices must meet the following standards: Accurate to at least 0.1°C • Temperature Accurate to at least 0.1% CO •... -
Page 11: Receiving Your Unit
6. Verify that the correct number of accessory items has been included. Carefully check all packaging for accessory items before discarding. Included Accessories Model Copper Pan Token Humidification Pan Access Port Stopper* Leveling Feet SCO5A SCO10A Model Chamber HEPA Filter Chamber Filter Cap Tubing Kit Ceiling Air Duct SCO5A... -
Page 12: Orientation Photos
RECEIVING RIENTATION HOTOS SCO5A Back of Unit In Port Fuse in Power Inlet USB-Style Port Sample Port Control Panel (Side of Unit) Access Port (Side of Unit) Chamber Door Handle Door Gasket Chamber Gasket Ceiling Air Duct Door Latch Chamber HEPA Filter... - Page 13 RECEIVING SCO10A See the SCO5A depiction on the previous page for details on the individual incubators in the stack. Top Incubator Mounting Bracket and SCO10 A Data Plate Bottom Incubator 13 | P a g e...
-
Page 14: Recording Data Plate Information
Record the unit model number, serial number, and part number below for future reference Customer Support needs this information to provide accurate help during support calls and emails. SCO5A • The data plate is located on the inside of the incubation chamber door in the top right corner. -
Page 15: Installation
INSTALLATION NSTALLATION ROCEDURE HECKLIST For installing the unit in a new workspace location. Pre-Installation Verify a CO gas supply source suitable for your application is available and can be connected to the incubator, page 9. Check that the required ambient conditions for the unit are met, page 16. -
Page 16: Required Ambient Conditions
INSTALLATION EQUIRED MBIENT ONDITIONS These units are built for use indoors at room temperatures between 15°C and 30°C (59°F and 86°F), at no greater than 80% Relative Humidity (at 25°C / 77°F The ambient temperature should not change by 2°C (3.6°F) or more during operation. Operating outside these conditions may affect the incubator temperature performance. -
Page 17: Power Source Requirements
These units are intended for 110 – 120 volt, 50/60 Hz applications at the following amperages: Model Amperage Model Amperage SCO5A 6.0 Amps SCO10A 6.0 Amps Standard *The SCO10A comes with two power cords. It requires 6.0 amps for each cord. -
Page 18: Lifting And Handling
INSTALLATION IFTING AND ANDLING The unit is heavy. Use appropriate lifting devices that are sufficiently rated for these loads. Follow these guidelines when lifting the unit. Lift the unit only from its bottom surface. • Doors, handles, and knobs are not adequate for lifting or stabilization. •... -
Page 19: Install The Incubator
INSTALLATION NSTALL THE NCUBATOR Install the unit in a workspace location that meets the criteria discussed in the previous entries of the Installation section. EIONIZED AND ISTILLED ATER Do not use deionized water to clean the unit, even if DI water is readily available in your laboratory. The use of deionized water may corrode metal surfaces and is not covered by the •... -
Page 20: Install Chamber Hepa Filter And Duct
INSTALLATION HEPA F Chamber NSTALL HAMBER ILTER AND Ceiling Air Duct Note: Exercise caution to avoid striking the sensors and blower fan wheel on the chamber ceiling when installing the duct. Note: The incubator must be turned off and unplugged when carrying out this procedure. -
Page 21: Shelving Installation
INSTALLATION HELVING NSTALLATION Install the shelving and in the incubation chamber. Install the shelf standard rails. • Align the keyhole slot of the standard with the mounting peg on the side of the chamber wall. • Mount the shelf standard. Install the shelf slides. -
Page 22: Connect To The Co Supply
Chamber Dual-Stage CO Optional Tubing Kit Connects to 3/16” Pressure Regulator with Inline HEPA Filter (4.76 mm) ID Tubing SCO5A SCO10A “IN” “IN” “IN” Connect the supply source to each incubator. The SCO10A requires a CO supply for each chamber. -
Page 23: Access Port Stopper
INSTALLATION CCESS TOPPER Each incubator ships with a silicone stopper installed in the access port located on the right side of the incubation chamber interior. The stopper should always be installed inside the chamber to obtain the • best temperature uniformity and prevent condensation from forming inside the port. - Page 24 INSTALLATION 24 | P a g e...
-
Page 25: Graphic Symbols
GRAPHIC SYMBOLS The unit is provided with graphic symbols on its exterior. These identify hazards and adjustable components as well as important notes in the user manual. Symbol Definition Consult the user manual Consulter le manuel d'utilisation Temperature display Indique l'affichage de la température Over Temperature Limit system Thermostat température limite contrôle haute AC Power... - Page 26 SYMBOLS 26 | P a g e...
-
Page 27: Control Panel Overview
CONTROL PANEL OVERVIEW Control Panel Power Switch Power is supplied and the green Power On light illuminates when the switch is in the ( I ) ON position. Over Temp Safety This graduated dial sets the mechanical heating cut off for the Over Temperature Limit system (OTL). The OTL helps prevents unchecked heating of the chamber in the event of an electronics failure or external heat spike. - Page 28 CONTROL PANEL Set CO Display and Controls Shows the current concentration of CO as a percentage of the incubation chamber Set CO atmosphere. The display has a range of OFF (0%) to 20% and an accuracy of 0.1%. The display shows “LO” until the CO sensor registers a concentration in the chamber greater than 0%.
-
Page 29: Operation
OPERATION HEORY OF PERATION Heating When powered, the incubator heats to and maintains a user-selected target setpoint in the incubation chamber. The incubator senses the chamber air temperature using a solid-state probe mounted on the chamber interior wall. When the incubator detects that the chamber temperature has dropped below the target setpoint, it pulses power to heating elements on the surface of the air-jacket insulation space and in the outer chamber door. - Page 30 OPERATION Atmosphere Set CO The incubator also controls and maintains the gas concentration of CO in the chamber atmosphere by operating an internal injection solenoid valve connected to a gas input port. The incubator monitors the CO concentration level in the chamber using an infrared sensor located in the recirculation duct.
-
Page 31: Put The Incubator Into Operation
OPERATION Note: From a cold start, the incubator requires 8 hours to come up to and stabilize at temperature and humidity levels prior to loading samples. Stabilization safeguards samples. UT THE NCUBATOR INTO PERATION Perform the procedures below after the unit has been installed in a new workplace location. These prepare the incubator for normal use. - Page 32 OPERATION Continued from the previous page. Run the unit for at least 8 hours (for example, overnight) with chamber doors closed prior to: Setting the Over Temperature Limit (next step). • Loading samples. • This helps ensure a stable temperature environment. Perform the Set the Over Temperature Safety procedure on...
-
Page 33: Humidify The Incubator
OPERATION Note: Each SCO10A incubator chamber must be independently humidified. UMIDIFY THE NCUBATOR The humidification pan must be filled with water in order for the incubator to achieve its stated temperature uniformity specification. Humidifying the chamber helps slow the drying of samples in open, “breathable” containers. Always place and secure the copper token in the pan to slow the growth of microbiological •... -
Page 34: Set The Temperature Setpoint
OPERATION Note: Each SCO10A incubator chamber temperature must be set independently. ET THE EMPERATURE ETPOINT Perform the steps below to adjust the setpoint to your process or application temperature. Set the Over Temperature Limit control to its maximum setting, if not already set to max. This prevents the heating cutoff system •... -
Page 35: Muting The Audible Temperature Alarm
OPERATION UTING THE UDIBLE EMPERATURE LARM Audible and visual deviation alarms activate if the incubation chamber temperature deviates by 1°C above or below the temperature setpoint. The low deviation alarm has a delay of 15 minutes to prevent the low alarm from sounding each time the doors are opened, causing a short-lived drop in temperature. -
Page 36: Start A Flow Of Co
OPERATION Note: Ensure that each incubation chamber in the SCO10A is connected to its own CO supply. TART A LOW OF Gas Cylinder Open the cylinder valve to supply CO to the regulator. Set the cylinder regulator flow setting. Set the regulator to deliver 15 – 20 Pounds per Square Inch (psi) to the incubator •... -
Page 37: Set The Co Setpoint
OPERATION Note: Each SCO10A incubator chamber CO setpoint must be set independently. ET THE ETPOINT The incubator comes from the factory with the CO setpoint set to Off. Set the setpoint percentage to the gas concentration required by your study or production protocol. Navigate to the CO Setpoint Adjustment mode Briefly push and release either the Up or Down arrow... -
Page 38: Muting The Audible Co Alarm
OPERATION UTING THE UDIBLE LARM Audible and visual deviation alarms activate if the incubation chamber CO concentration deviates by 1% above or below the CO setpoint. The low deviation audible alarm has a delay of 15 minutes to prevent the low alarm from sounding each time the doors are opened, causing a short-lived drop in CO concentration. -
Page 39: Set The Over Temperature Safety
OPERATION Note: Test the OTL system at least once per year to verify its functionality. Failure to set the OTL voids the manufacturing defect warranty if over temperature damage occurs. The OTL for each SCO10A incubator chamber must be set independently. Note: ET THE EMPERATURE... -
Page 40: Loading Samples
OPERATION OADING AMPLES The manufacturer strongly recommends waiting at least 8 hours after putting the incubator in operation before loading samples in the chamber. This safeguards against temperature instability. Samples should be placed at least 1 inch (25 mm) away from the chamber walls. •... -
Page 41: Data Output Capabilities
OPERATION UTPUT APABILITIES USB Outputs The incubator generates data outputs describing the chamber temperature and CO concentration percentage as a digital log line, once per minute. These outputs are transmitted through a USB port located on the back of the unit using RS232 serial protocol. Required Software Viewing and logging this output requires a terminal emulator program such as the open source (BSD license) emulator, Tera Term. -
Page 42: Condensation And The Dew Point
OPERATION ONDENSATION AND THE OINT Relative humidity inside the incubator chamber should never be allowed to exceed 95%. Exceeding this threshold will likely result in condensation, possible leaks around the incubator, and may cause corrosion damage if allowed to continue for any significant length of time. Condensation takes place whenever the humidity level in the incubator chamber reaches the dew point. -
Page 43: User Maintenance
USER MAINTENANCE Warning: Disconnect the unit from its power supply prior to performing maintenance or services. Avertissement: Débranchez cet appareil de son alimentation électrique avant d'effectuer la maintenance ou les services. LEANING AND ISINFECTING If a hazardous material or substance has spilled in the unit chamber, immediately initiate your site Hazardous Material Spill Containment protocol. -
Page 44: Minimizing Contamination Exposure
MAINTENANCE Disinfecting For maximum effectiveness, disinfection procedures are typically performed after cleaning. Keep the following points in mind when disinfecting the unit. Turn off and disconnect the unit to safeguard against electrical hazards. • Disinfect the unit chamber using commercially available disinfectants that are non-corrosive, •... -
Page 45: Gas Lines And Hepa Filters
MAINTENANCE HEPA F INES AND ILTERS For the Optional Filtered Gas Tubing Kit The manufacturer recommends replacing the in-line gas HEPA filters once per year or “IN” when a filter is noticeably discolored. HEPA filters are directional and must be installed facing in the correct direction. •... -
Page 46: Replace The Chamber Hepa Filter
MAINTENANCE HEPA F Step 1 EPLACE THE HAMBER ILTER Front Note: Always turn off and unplug the incubator before carrying out this procedure. Replace the filter at least once per year, or when the filter is noticeably discolored. Exercise caution when removing the ceiling air duct. A plastic Step 2 blower fan and the fragile head of the temperature and CO Back... -
Page 47: Calibrate The Temperature Display
MAINTENANCE ALIBRATE THE EMPERATURE ISPLAY Note: This procedure requires a temperature reference device. Please see the Reference Sensor Device entry on page 10 for the device requirements. Each SCO10A incubation chamber must be independently calibrated to its temperature Note: display. Temperature calibrations match the temperature display to the actual air temperature inside the incubation chamber. - Page 48 MAINTENANCE 6. The unit temperature must be stable in order to perform an accurate calibration. The incubator must run for at least 8 hours prior to conducting a calibration. • The temperature is considered stabilized when the incubator has operated with the door •...
- Page 49 MAINTENANCE Temperature Calibration Continued Place the display in temperature calibration mode. a. Press and hold both the Up and Down temperature arrow buttons simultaneously for approximately 5 seconds. b. Release the buttons when the temperature display shows the letters “C O”. The display will begin flashing the current temperature display value.
- Page 50 MAINTENANCE Temperature Calibration Continued Compare the reference device reading with the chamber Reference Device temperature display. If the reference device and the chamber temperature • display readings are the same or the difference falls within the range of your protocol, the incubator is now calibrated for temperature.
-
Page 51: Calibrate The Co 2 Display
MAINTENANCE ALIBRATE THE ISPLAY Note: This procedure requires a gas reference device. Please see the Reference Sensor Devices entry on page 10 for the device requirements. Note: Each SCO10A incubation chamber must be independently calibrated to its CO display. Gas calibrations are performed to match the incubator CO display to the actual CO concentration inside the incubation chamber. - Page 52 MAINTENANCE 5. The CO concentration in the incubation chamber must be stable in order to perform an accurate calibration. The incubator must run for at least 8 hours prior to conducting a calibration. • The CO concentration is considered stabilized when the incubator has operated with the •...
- Page 53 MAINTENANCE Calibration Continued Place the incubator CO display in its calibration mode. a. Press and hold both the Up and Down CO arrow buttons simultaneously for approximately 5 seconds. b. Release the buttons when the CO display shows the letters “C O”. The display will then begin flashing the current CO display value.
- Page 54 MAINTENANCE Calibration Continued Compare the reference device reading with the incubator CO display again. Reference Device If the reference device and the incubator display readings • are the same or the difference falls within the range of your protocol, the incubator is now calibrated for CO -OR- ...
-
Page 55: Unit Specifications
We reserve the right to alter technical specifications at all times. EIGHT Model Shipping Unit SCO5A 238 lb / 108 kg 200.0 lb / 91.0 kg SCO10A 460 lb / 209 kg 400.0 lb / 182.0 kg... -
Page 56: Max Shelves For Unit
SPECIFICATIONS HELVES Model Shelves SCO5A SCO10A APACITY Model Cubic Feet Liters SCO5A 142.0 SCO10A* 142.0 *Each Chamber Model Range Accuracy Recovery Time ± 0.1% 0 – 20% Less than 5 minutes EMPERATURE Model Range Uniformity Stability Ambient +5ºC to 60ºC ±... -
Page 57: Parts List
PARTS LIST Part Part Number Part Part Number Gas Line HEPA Access Port Stopper Filter 2800525 7750506 Chamber HEPA Filter Humidification Pan 995-00015 2800517 Chamber HEPA Filter Cap Leveling Foot 2700512 6500506 Power Cord 115 Ceiling Air Duct volt 15 Amp,9ft (Chamber) 5 in (2.86m) NEMA 5-15P... -
Page 58: Accessories
Accessories and replacement parts can be ordered online at parts.sheldonmfg.com. If the required item is not listed online, or if you require assistance in determining which part or accessory you need contact SHEL LAB by emailing parts@sheldonmfg.com or by calling 1-800-322- 4897 ext. 3 or (503) 640-3000 ext. 3. - Page 59 PARTS 59 | P a g e...
