GEIGER -MODULARline Operating Instructions Manual
Tubular motor, motor control for rolling shutters with stoppers and anti-lift device
Hide thumbs
Also See for GEIGER-MODULARline:
- Operating instructions manual (8 pages) ,
- Operating instructions manual (10 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for GEIGER GEIGER-MODULARline
Summary of Contents for GEIGER GEIGER-MODULARline
- Page 1 Tubular motor: GEIGER-MODULARline Motor control: GEIGER-SoftPerfection (GR45..E03) for rolling shutters with stoppers and anti-lift device Bedienungsanleitung Operating Instructions Manuel d’utilisation Manual de instrucciones Istruzioni per l’uso www.geiger.de...
-
Page 2: Table Of Contents
10. End position correction ...........8 11. Technical data ..............8 12. Declaration of conformity ..........8 13. Information for the specialist electrician .......9 14. Notes on waste disposal ..........9 15. What to do if… ..............10 Gerhard Geiger GmbH & Co. KG | 100W0539 0613... -
Page 3: Geiger-Softperfection: Special Features
Ready! Plug & Play! Cloth protection with the Soft-System • The GEIGER Soft position ensures that the hanging stops a few millimetres before reaching the end position. The hanging is thus optimally protected. Two exceptions: the programming runs and the reference runs after 50 cycles. -
Page 4: General Information
2. General information Dear customer, By purchasing a GEIGER tubular motor you have decided on a quality product from GEIGER. Thank you very much for your decision and the confidence placed in us. Before you put this drive into operation please observe the following safety information. -
Page 5: Intended Use
If the tubular motors are used for other applications and/or modifications are performed to the tubular motors, which have not been discussed with GEIGER Antriebstechnik, then the manufacturer is not liable for personal injury and/or damage to property and for consequential damage. -
Page 6: Installation Instructions
* The magnetic shaft M45B033 must be installed into the motor with all electronic and radio cont- rolled limit stops such as GEIGER-Easy (GR45..E01), GEIGER-Soft Zero (GR45..E02), GEIGER- SoftPerfection (GR45..E03), GEIGER-SoftPerfection-S (GR45..E04) and GEIGER-VariousWireless (GR45..F01). -
Page 7: Setting Of End Stops
The running direction in which the obstacle was recognized is blocked. The block is removed if the motor has been operated in the opposite direction for a certain time. An obstacle must thus first be released before the motor can be operated again in the direction of the obstacle. www.geiger.de... -
Page 8: End Position Correction
It is authorised for use in all EC member states and in Switzerland without any need of prior registration. The Declaration of Conformity concerning this product is available on our website: www.geiger.de. Gerhard Geiger GmbH & Co. KG | 100W0539... -
Page 9: Information For The Specialist Electrician
Waste disposal of electric and electronic equipment Electronic equipment or batteries cannot be discarded along with the normal household waste. Keep for more information on the recycling and disposal methods envisaged by the local regula- tions in your area. www.geiger.de... -
Page 10: What To Do If
Setting is not possible. • Magnetic counter M45B033 not mounted. Remove the end stop system and place the magnetic counter into the motor. Gerhard Geiger GmbH & Co. KG | 100W0539 0613... - Page 11 www.geiger.de...
- Page 12 They will be happy to assist you. Gerhard Geiger GmbH & Co. KG Schleifmühle 6 D-74321 Bietigheim-Bissingen Telephone: +49 (0) 7142 938-0 Telefax: +49 (0) 7142 938-230 E-Mail: info@geiger.de Internet: www.geiger.de Gerhard Geiger GmbH & Co. KG | 100W0539 0613...
