General

Meaning of symbols and
corresponding information
In this manual, the symbols and safety
wordings shown on this page are intended to
communicate a particular risk to persons,
material assets, or the environment.
All safety instructions must be respected
by person exposed to these risks. The safety
instructions must be communicated to all
other persons.
Instructions attached directly to the equip-
ment, such as
• rotational direction arrows
• fluid connection labels, etc.
must be respected and remain perfectly
legible.
It is essential to read these instructions
thoroughly and to respect the safety instruc-
tions given.
6
Hazard symbols
Symbol Standard
DIN 4844-2 W000
DIN 4844-2 W008
DIN 4844-2 W026
DIN 4844-2 W028
DIN 4844-2 W027
DIN 4844-2 W55
Table 1
Meaning
General hazard
Voltage
Hot surface
Slippery floor
Risk of hand injury
Risk of pollution
