Installation/Operation guide Electronic air shutoff assembly Model V340HH D A N G E R Date of issue January 2015 Form number 404633A Read manual prior to installation or use Section of this product. Keep manual nearby for Page future reference. Failure to follow instructions and safety precautions may result in death or serious injury.
Contents Explanation of signal Safety words for safety Read and carefully observe these Explanation of signal words for safety instructions before installing, operating or troubleshooting this equipment. Safety ......Notice Owner/operator responsibility .
Owner/operator Table 1 responsibility Specifications Air pressure 40 to 150 psi (2.7 to 10.3 bar) It is the responsibility of the owner/operator Operating temperature –40 to +150° F (–40 to 5° C). to properly use and maintain this Power 9 V battery (included in packaging, not installed in assembly) equipment.
Installation Fig. 2 1 Turn off pump. 2 Remove four screws (9) and top plate (10) from module on back of pump († fig. 1). Notice Save original rectangular plate (10) for future use. Fig. 1 – The first row will display the overrun Notice controller software version Ensure all three wires under back...
Page 5
DIN Connector Wiring Fig. 3 1 Referring to fig. 3, detach the DIN sock- et (26) from the side of the PCB enclo- sure (3). 2 Unscrew cap (27). 3 Pull out three washers (28), ( 29), (28) located inside the DIN socket (26). 4 Remove screw (30) and nut (31) from DIN socket (26).
Operation Fig. 5 First use setup Notice Follow the one time procedure which is detailed below for first use set- up only. Do not use this procedure after first use setup. 1 Holding TEST (22), press B (21) + A (20) + B (21) within 5 seconds (†...
Overrun mode Notice Notice Pump switched off due to overrun To exit setup mode without saving Setting cycles/minute value to 00 condition any changes, do not press any buttons places unit in bypass mode, disabling Refer to table 4 for overrun mode options. for 30 seconds.
Replace 9 V battery Fig. 6 1 Press TEST (22) († fig. 5, pg. 6) to disable pump activity. 2 Remove two socket head cap screws (12) († fig. 6) in the indented part on rear lip of overrun controller (8) and two screws (13) on the rear side corners of back cover (3).
Solenoid replacement 8 Confirm error code “0C” is no longer (error code 0C) present in display (17). 1 Remove two socket head cap screws 9 Attach brackets (2) to valve cap (5) using (12) in the indented part on rear lip of four hex screws (23).
Fig. 9 Table 8 Parts list Item no. Description Part no. Pressure switch kit 286425 Mounting plate kit 286431 (right side) 286431 (left side) PCB enclosure kit 286427 Solenoid valve kit 286428 Valve cap assembly kit 286429 End plug kit 286424 Seal kit 286423...
Page 11
Lincoln industrial Special limited 5 year warranty This warranty gives you specific legal limited oil meters, limited fluid control standard warranty rights. You may also have other rights that valves, aod (air-operated diaphragm vary by jurisdiction. pumps) Customers not located in the Western Standard limited warranty Hemisphere or East Asia: Please contact Lincoln warrants the 712 series control...
Every care has been taken to ensure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein. SKF PUB LS/I4 14137 EN.US · January 2015 · Form 404633A lincolnindustrial.com...
