- Page 1 User and maintenance instructions Lubrigun® lubrication unit Models 917, 989, 86267 with air operated grease pumps 82050, 82716, 85100*, 802330* and 83513 Date of issue July 2017 Form number 403404 Version * Indicates change.
-
Page 2: Table Of Contents
EC-representative‘s address. EC-Representative SKF Lubrication Systems Germany GmbH Heinrich-Hertz-Str. 2-8 DE - 69190 Walldorf Robert Hoefler, Director Product Development/ Product Engineering... -
Page 3: Description
Description Installation Models 82050, 82716, 83513, 85100 and Typical drum and pail hookups are described 802330 are air operated grease pumps only as guide in selecting and installing designed to pump low and medium viscosity system. materials (grease) from drums and pails. Accessories Safety information •... -
Page 4: Typical System Hookup
Typical system Assembly WARNING hookup instructions Do not exceed 90 psi (6 bar) air pressure to pump when using whip hoses. Accessory item whip hoses for dispensing valve are rated at 4 500 psi (310 bar). 1 Determine drum or pail system for Assemble unit as shown in diagrams. -
Page 5: Pressure Relief Procedure
Pressure relief Operation WARNING procedure Failure to heed the following warnings including misuse, over pressurizing, modify- Inspect before use ing parts, using incompatible chemicals and fluids, or using worn or damaged parts, may Always perform this procedure before Any pump that appears to be damaged in result in serious personal injury and/or equipment damage, fire, explosion, or prop- servicing:... -
Page 6: Lubrication
Lubrication Air line filter/regulator/lubricator is recom- mended for use with Lincoln pump to remove harmful dirt and moisture from compressor air supply, and to provide auto- matic air motor lubrication. If air lubricator is not used, the following procedure should be performed daily: 1 Disconnect air coupler from air fitting. -
Page 7: Exploded Views
Fig. IPB1 Model 917, 120 lbs. (54 kg) container, 50:1 ratio Screw included with 46007. - Page 8 Fig. IPB2 Model 989, 35 lb. (15,8 kg) container, 50:1 ratio...
- Page 9 Fig. IPB3 Model 86267, 802330, 35 lb. (15,8 kg) container, 50:1 ratio...
- Page 10 Fig. IPB4 Model 85100, 60 lb. (27 kg) container, 50:1 ratio...
-
Page 11: Parts List
Refer to separate instructions: 740 Control valve: 403742 815 Air coupler: 405457 81387 Swivel: 404221 82716 Basic pump: 404216 Parts list Used on model Item no. Description Part number 86267 85100* 802330* Quantity Small swivel, universal D 81387 Coupler and extension Coupler, air Coupler, air-nipple 11659... - Page 12 | lincolnindustrial.com ® SKF, Lincoln and Lubrigun are registered trademarks of the SKF Group. © SKF Group 2017 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein.
