Model Numbers

Alarm Valve Combo Unit
The "L" Defines the
Language:
U = English (NFPA)
E = English (CSA/ISO)
F = French (CSA/ISO)
S = Spanish (NFPA)
Notes:
• The power supply requires 1 gang per box.
• Example: English, 3 valves, 1/2" Oxygen, 3/4" Medical Air and 1-1/4" Medical Vacuum. Will be in a
4 gang box, not a 3 gang: AVU-1O2A4V
• The 1-1/2" valve will have an empty space above the valve.
• Example: a box with a 1/2" Oxygen, 3/4" Medical Air and 1-1/2" Medical Vacuum and a power
supply will require a 5 gang box not a 4 gang box.
• The 2" valve will be assembled in a 6-1/2" deep box and shall accommodate up to a maximum of four
gases. The 2" valve shall be positioned on the bottom of the assembly. The height measurements
of the 6-1/2" deep valve box are the same as the 3-7/8" deep valve box. When comparing height
measurements, consider the gap above the 2" valve.
• Example: a valve box with 1/2" valve, 2" valve and a power supply would be in a 3 gang, 6-1/2"
deep box, which would be the same height as the 4 gang, 3-7/8" valve box.
• 2-1/2" and 3" valve assemblies are only offered as singles.
20 Amico Corporation
AVL-XGXGXGXGXGXGXG
Replace "X" with the Valve Size:
1 = 1/2" [1.3 cm]
2 = 3/4" [1.9 cm]
3 = 1" [2.5 cm]
4 = 1-1/4" [3.2 cm]
5 = 1-1/2" [3.8 cm]
6 = 2" Full Port [5.1 cm]
The "G" Defines the Gas:
05 O = Oxygen
07 A = Medical Air
10 V = MedVac
12 2 = Nitrous Oxide
15 N = Nitrogen
20F C = Carbon Dioxide
W = WAGD (NFPA)
E = AGSS (ISO)
I = Instrument Air
