USB-1616FS User's Guide

Internal components

Major components on the USB-1616FS are shown in Figure 3-1.
!
Two (2) USB connectors
!
Two (2) external power connectors
!
USB LED
!
PWR LED
!
Four (4) Screw terminal banks
USB IN
USB
OUT
PWR LED
USB LED

USB OUT connector

The
connector is a downstream hub output port intended for use with other Measurement
USB OUT
Advantage products only. The USB hub is self-powered, and can provide 100 mA maximum current at 5 V.
The USB out connector is labeled
For information on daisy chaining to other Measurement Advantage products, refer to
additional modules to the USB-1616FS

USB IN connector

Connect the
connector to the USB port on your computer (or USB hub connected to your
USB IN
computer). The USB in connector is labeled
POWER IN
POWER
OUT
I/O screw terminal connectors
Figure 3-1. USB-1616FS module components
on the enclosure and on the board.
USB OUT
on page 3-7.
USB IN
I/O screw terminal connectors
on the enclosure and on the board.
3-2
Functional Details
Daisy chaining
