Overview
72
Caution
On socket 4, use the WTW probe StirrOx G only.
1.4

Operating structure

The following overview diagram shows which keys you have
to press to select between the different measuring modes:
Note
The oxygen concentration, oxygen saturation, and oxygen
partial pressure measuring modes only appear if a D. O.
probe with temperature probe is connected to the instru-
ment.
Note
When a D. O. probe with temperature probe is connected,
the measuring instrument recognizes the probe and auto-
matically switches to the previously selected oxygen mea-
suring mode. As soon as the probe is disconnected, the
instrument switches to the pH or Redox measuring mode.
