PRODUCT OVERVIEW

Power Measurements

Multi-Tech Systems, Inc. recommends incorporating a 10% buffer into your power source when determining
product load.

MTCM-LAT3 Power Draw

Radio protocol
5 Volts
WDCMA
LTE
Note:
1. Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
2. TX Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what
transmission scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
3. Inrush Charge: The total inrush charge at power on.

MTCM-LSP3 Power Draw

Radio protocol
5 Volts
LTE
Note:
1. Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
2. TX Pulse: The average peak current during a GSM850 transmission burst period or HSDPA/LTE
connection. The transmission burst duration for GSM850 can vary, depending on what
transmission scheme is being deployed (GPRS Class 8, Class 10, GSM, etc.).
3. Inrush Charge: The total inrush charge at power on.
12
Sleep mode Live idle
(mA) (mA)
N/A 63
N/A 72
Sleep mode Live idle
(mA) (mA)
N/A 63
No data Max power
1
(mA) (mA)
62 625
69 457
No data Max power
1
(mA) (mA)
86 605
®
MultiConnect MicroCell MTCM-LAT3 and -LSP3 User Guide
TX pulse Inrush charge
2 3
(mA) (mC)
680 0.287
524 0.287
TX pulse Inrush charge
2 3
(mA) (mC)
668 0.133
