Single Slot LED/Switch Module Detail Reference

Switches
Visible area
8-1/4" H,
2" W
(210 mm
x 51 mm)
8 Switches
with 16 LEDs:
4100-1282, R/Y
4100-1283, Y/Y
4100-1284, R/G
4100-1296, G/Y

Dual Slot LED/Switch Module Detail Reference

One switch per
control, on/off
Visible area
8 1/4" H, 2" W
(210 mm x 51 mm)
LED/Switch Modules
Label insert
Control
Custom
label area
East
Wing
West
LEDs
Wing
South
Wing
North
Wing
Annex
Garage
Basement
Boiler
Room
16 Switches 8 Switches
with 16 LEDs: with 8 LEDs:
4100-1300, R/Y 4100-1280, R
(pluggable LEDs) 4100-1281, Y
Label insert
Custom
label area
Red LEDs
One switch
per function
4100-1287
24 Switches, 24 LEDs
Primary
function label
Additional
function labels
Fan Fan
On Off
Designates area
for each column of
switches and LEDs
Switch
LEDs
LED Color Legend:
Red, Yellow, Green;
R/Y = Red on top,
Yellow on bottom;
R-Y = Red on left,
Yellow on right
16 Switches
with 16 LEDs:
4100-1278, R-Y
4100-1285, R
On On
Off Off
Auto Auto
On On
Off Off
Auto Auto
On On
Off Off
Auto Auto
On On
Off Off
Auto Auto
HOA Modules, 8 Controls (3 switches each), 24 LEDs:
4100-1286, with labeled switches (shown)
4100-1295, with unlabeled switches (not shown)
6
LED Modules
16 LEDs:
8 LEDs:
4100-1277, R/Y
4100-1276, R
(pluggable LEDs)
(pluggable LEDs)
Primary function labels
Green LED (On)
Red LED (Off)
Green LED (Auto)
