LED/Switch Module Product Selection (Continued)
LED/Switch Controller Modules and Accessories
Model Description
64 LED/64 Switch Controller Module with mounting plate; controls up to 64 LEDs
4100-1288 and interfaces to up to 64 switches; mounts behind the LED/switch modules and
has provisions for one 4100-1289 Controller Module
64 LED/64 Switch Controller Module without mounting plate; mounts on extra
4100-1289
space of 4100-1288; controls an additional 64 LEDs and 64 switches
4100-0636 Harness Kit, Power and Communications
4100-0641 Harness Kit, 26 Position Flex Cable, 14-1/2" (368 mm) long
24 Point I/O Module for external connections, select each point as either input or output;
4100-1290
2" (51 mm) wide, 1 Slot
LED/Switch Module Slide-in Labels, required when LED/switch or LED only modules are present;
4100-1294
order one per cabinet
Single blank 2" display cover; order as required (8 fill a bay front); two maximum in a row between LED/switch
4100-1279
modules
Panel Mounted Printer (refer to pages 6 and 7 for printer details)
Model Description
4100-1293 Panel Mount Thermal Printhead Printer, supplied with one roll of paper
4190-9803 Replacement Paper for 4100-1293 Printer, one roll
LED/ Switch Modules and Controllers Specifications
(For additional LED/Switch Module information, refer to Installation Instructions 574-843)
64 LED/64 Switch Controller Modules (4100-1288 and 4100-1289)
Input Voltage
Current, No LEDs On
Current, All 64 LEDs On
Mounting Reference
Controllers per Bay
Bay Location Reference
Clearance Behind Controller Module
24 Point I/O Module (4100-1290)
Module Current
Switch Input Details
Output Current
Output Details
General Specifications
Operating Temperature Range
Operating Humidity Range
Additional 4100ES Product Reference
Subject
4100ES Basic Panels with SPS Power Supplies
4100ES Emergency Voice/Alarm Equipment
NDU with SPS Power Supplies for 4120
Network
4100ES Remote Annunciator Panels
InfoAlarm Command Center with SPS Power
Supplies
19 to 33 VDC, from control panel
20 mA @ 24 VDC
180 mA nominal @ 24 VDC (2.5 mA per LED)
212 mA maximum @ 19 VDC (3.0 mA per LED)
Bracket of 4100-1288 attaches to the back of the LED/switch modules
Maximum of two per bay; for control of LED/switch modules within that bay only
Slots 1 & 2 or Slots 3 & 4; mounts onto the back of the LED/switch modules
Space accepts low profile 4100ES/4100U modules only
Supervisory = 34 mA; Alarm = 75 mA (add output currents separately)
Momentary or maintained, 2 or 3 position; max. distance is 2500 ft (762 m) or 65 Ω
150 mA @ 24 VDC per point; inrush current is limited for use with incandescent bulbs
Diode suppress relay loads at the coil; max. distance is 600 ft (183 m) or 2 Ω
32° to 120°F (0° to 49° C)
Up to 93% RH, non-condensing @ 90° F (32° C) maximum
Data Sheet Subject
S4100-0031 NDU with SPS Power Supplies for ES Net
4100ES Basic Panels with EPS Power
S4100-0034 Supplies
InfoAlarm Command Center with EPS
S4100-0036 Power Supplies
NDU with EPS Power Supplies for 4120
S4100-0038 Network
S4100-0045 NDU with EPS Power Supplies for ES Net
5
NOTE: LED/switch controllers
and their connected modules
must be in the same bay.
One of each is required per 4100-1288 that is
located in the same bay as two Flex-35/50
amplifiers and an SPS
