Simplex 4100ES Operating Instructions Manual page 4

LED/Switch Module Product Selection
LED/Switch Modules, General Purpose (LED/switch controller and label kit is ordered separately)
Model LEDs per Switch
4100-1280 One
4100-1281 One
4100-1282 Two
4100-1283 Two
4100-1284 Two
4100-1296 Two
4100-1285 One
4100-1278 One
4100-1300* One
4100-1287 One
* UL, ULC, and CSFM listed only.
LED Only Modules and LED Kits (LED/switch controller and label kit is ordered separately)
Model Description
Eight (8) LED Module with Red LEDs; custom label area per
4100-1276
module and per LED
Sixteen (16) LED Module; Red LED on top and Yellow LED
4100-1277 on bottom at each position; custom label area per module
and per LED pair
4100-9843 Yellow
Kits of 8 LEDs; order as required for modules with pluggable LEDs to change LED color on-site per
4100-9844 Green
application requirement; compatible with LED Modules 4100-1276, 4100-1277, and 4100-1300
4100-9845 Red
(Blue is typically used for Ancillary Device status indication per ULC S527)
4100-9855 Blue
LED/Switch Modules, HOA (Hand-Off-Auto) with Green/Red/Green LEDs
(LED/switch controller and label kit is ordered separately)
Model Operation
Eight function HOA (On, Off, Auto) Control Module with
4100-1286
labeled switches; custom label area per module and per
LED/switch set
4100-1295 Eight function HOA (On, Off, Auto) Control Module, same as 4100-1286 except switches are unlabeled
LED/Switch Modules, HOA (Hand-Off-Auto) with Green/Red/White LEDs for IBC Applications
(LED/switch controller and label kit is ordered separately)
Model Operation
Eight function HOA (On, Off, Auto) Control Module with
labeled switches; LED colors meet International Building
4100-1275
Code (IBC) requirements; custom label area per module
and per LED/switch set
4100-1299 Eight function HOA (On, Off, Auto) Control Module, same as 4100-1275 except switches are unlabeled
LED/Switch Modules, HOA (Hand-Off-Auto) with Green/Yellow/Green LEDs
(LED/switch controller and label kit is ordered separately)
Model Operation
Eight function HOA (On, Off, Auto) Control Module with
4100-1302** labeled switches; for applications requiring no red LEDs;
custom label area per module and per LED/switch set
4100-1301** Eight function HOA (On, Off, Auto) Control Module, same as 4100-1302 except switches are unlabeled
** UL, ULC, and CSFM listed only.
(panel mounted switches are momentary pushbutton)
LED Color(s)
Red
Yellow
Red on top, Yellow on bottom
Yellow on top and bottom
Red on top, Green on bottom
Green on top, Yellow on bottom
Red
8 Red on left, 8 Yellow on right
With pluggable LEDs; shipped
Red on top, Yellow on bottom
Red
Custom Label Area
Per module and per switch
Per module and per switch
One per column of 8
LED/switch pairs (see
illustration on page 2)
Per module and per
LED/switch pair
Per module and per switch
LEDs are pluggable; select LED kits as required to
change LED color
Switch Function (Location)
On (top)
Off (middle)
Auto (bottom)
Switch Function (Location)
On (top)
Off (middle)
Auto (bottom)
Switch Function (Location)
On (top)
Off (middle)
Auto (bottom)
4
LED Quantity Switch Quantity
8 8
16 8
16 16
24 24
LED Description
Green LED
Red LED
Green LED
LED Description
Green LED
Red LED
White LED
LED Description
Green LED
Yellow LED
Green LED
Continued on next page
S4100-0032-13 8/2018
