AG Pro Quint
700 / 800 / AWS (1700 / 2100) / 1900 MHz
In-Building Wireless
Smart Technology ™
Signal Booster
Contents:
Antenna Options & Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Quick Install Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing the Outside Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Finding the Strongest Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installing the Inside Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing a Wilson Electronics Signal Booster. . . . . . . . . . . . . . . . . . . . . . . . . .9
Powering up a Wilson Electronics Signal Booster . . . . . . . . . . . . . . . . . . . . . . .9
Understanding the Signal Booster Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Warnings and Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Guarantee & Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
Appearance of device and accessories may vary.
Note: This manual contains important safety and operating information. Please read and follow the instructions
in this manual. Failure to do so could be hazardous and result in damage to your Signal Booster.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wilson Electronics AG Pro Quint
Summary of Contents for Wilson Electronics AG Pro Quint
-
Page 1: Table Of Contents
Installing the Inside Antenna ........8 Installing a Wilson Electronics Signal Booster......9 Powering up a Wilson Electronics Signal Booster . -
Page 2: Antenna Options & Accessories
Quint’s control knobs allow the installer to optimize the gain on each of the frequency bands. The AG Pro Quint delivers up to 75 dB of gain and supports CDMA, GSM, EVDO, LTE, HSPA+ and WCDMA technologies. It can be paired with an Outside Directional Antennas and a variety of Wilson Inside Antennas to create a custom Signal Booster system. -
Page 3: Quick Install Overview
Quick Install Overview See Installation Diagram on page 3. Contact Wilson Electronics Technical Support Mon. - Fri. hours: 7am to 6pm MST. Team with any questions at 866-294-1660 1. Select a location to install the Signal Booster that is away from excessive heat, direct sunlight, moisture and has proper ventilation. -
Page 4: Installation Diagram
Outside Antenna and the Signal Booster. Typical Installation Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 eam with any questions at 866 294 1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST. -
Page 5: Before Getting Started
Surge Protector Power Strip Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 Contact Wilson Electronics Technical Support Team with any questions at 866 294 4 1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST. -
Page 6: Installing The Outside Antenna
Inside Antenna as this will cause the oscillation protection circuitry to shut down the Signal Booster (refer to page 10). Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST. -
Page 7: Finding The Strongest Signal
Antenna about 45 degrees at a time, while the second person is watching the signal strength on the phone inside the building. This allows you to read the Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. - Page 8 Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST.
-
Page 9: Installing The Inside Antenna
Multiple mounting 2-way 3-way 4-way options available (859957) (859980) (859981) 75 ohm 3-way (859994) 2-way (859993) Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST. -
Page 10: Installing A Wilson Electronics Signal Booster
6. Using multiple Signal Boosters in one installation could cause interference to the cell tower (except for the In-Line Signal Booster). 7. Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email tech@wilsonelectronics.com. Technical Support hours are Mon.- Fri. 7 am to 6 pm MST. -
Page 11: Understanding The Signal Booster Lights
Actual Gain that the Signal Booster is operating on. Since the Signal Booster adjusts gain automatically, there is no need to turn the gain down. If Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. - Page 12 *Note: If the antennas cannot be sufficiently separated, the Signal Booster will have to operate with reduced performance by decreasing the Gain until a green light is obtained. Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com. Mon.- Fri. Hours: 7 am to 6 pm MST.
-
Page 13: Warnings And Recommendations
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Wilson Electronics could void the authority to operate this equipment. - Page 14 All products are engineered and assembled in the company’s 100,000 square-foot headquarters in St. George, Utah. Wilson Electronics has product dealers in all 50 states as well as in countries around the world. Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 or email: tech@wilsonelectronics.com.
-
Page 15: Guarantee & Warranty
Wilson Electronics. Wilson Electronics shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer if located within the continental U.S. -
Page 16: Specifications
Signal Booster Specifications AG Pro Quint Model Number 273470 Antenna connectors N-Female Antenna Impedance 50 Ohms Dimensions 8.875 x 6.0 x 1.5 inch (22.5 x 15.2 x 3.8 cm) Weight 2.8 lbs (1.270 kg) Frequency 698-746 MHz / 746-787 MHz / 824-894 MHz / 1850-1990 MHz / 1710-2155 MHz...
