- Page 1 DB Pro ™ Cellular Signal Booster 460103 Need help? www.WilsonElectronics.com Tech Support 866-294-1660 Mon.- Fri. Hours: 7 am to 6 pm MST...
-
Page 2: Table Of Contents
IN THE EVENT OF A POWER SURGE OR LIGHTNING STRIKE. Installation Instructions for the Following Wilson Electronics Signal Booster: DB Pro™ 4G Adjustable Gain 700 (Band 17,13) / 800 / 1900 (Band) / AWS (1700 / 2100) MHz Smart Tech ™ Signal Booster... -
Page 3: Package Contents
Read through all the installation and will help you get the best performance steps. This will help you know what to from your DB Pro 4G. You can find the expect from start to finish. strongest signal outside your building,... -
Page 4: Installation Details
Acceptable method: Check the bar the bar indicator. Go to www. wilsonelectronics.com/test-mode- indicator on your cell phone display instructions for help in finding the and note where the signal appears test mode for your phone. the strongest. (Note: cell phone bars are only an approximation of signal b. -
Page 5: Quick Install
(See page 4 for information on protector. The LSP is sold separately. lightning protection) Quick Install If your DB Pro 4G is working correctly, the lights will be green. If For more detailed instructions on the lights are orange or red, see the installation, read the description later “Troubleshooting”... -
Page 6: Signal Booster Installation
Inside Antennas. These can attach to the Signal Boost by using a splitter (sold separately). Contact Wilson Electronics for more information. The lights on the Signal Booster Ensure a minimum of 20 feet vertical should remain green . -
Page 7: Troubleshooting & Understanding Lights
You always Support Team for assistance: 866- want the lights to be green. 294-1660. Red indicates the DB Pro 4G has Fixing Orange Light Issues shut down to prevent oscillation If one or both lights on the Signal Booster (feedback). -
Page 8: Additional Faq
I know which MHz band my cell phone uses? Lights Off The DB Pro 4G works with all major If one or more of the lights on Signal North American cellular providers. Booster are off verify power to your surge Traditionally, 800/1900MHz are associated protected power strip. -
Page 9: Optional Equipment
75 Ohm Outside Antenna Kits Kit 301151-0610 • 75 Ohm Dome Antenna Kit 301111-0675 • 10’ RG6 Cable • Yagi Directional Antenna Kit 311135-5820 • 75’ RG6 Cable • 50 Ohm Wall mount Panel Antenna • N-Male to F-Female adapter •... -
Page 10: Safety Guidelines & Recommendations
Connecting the Signal Booster directly to the cell phone with use of an adapter will damage the cell phone. WARNING: Use only the power supply provided in this package. Use of a non-Wilson Electronics product may damage your equipment. WARNING: The Signal Booster unit is designed for use in an indoor, temperature-controlled environment (less than 150 degrees Fahrenheit). -
Page 11: Signal Booster Specifications
Signal Booster Specifications DB Pro 4G Specifications Model Number 460003 Antenna connectors F-Female Antenna impedance 50 ohms 6.5 x 4.5 x 1.75 inch Dimensions (16.5 x 11.4 x 4.4 cm) Weight 1.28 lbs (0.580 kg) Frequency 704-746 MHz, 776-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155 MHz... - Page 12 Returned Material Authorization (RMA) number supplied by Wilson Electronics. Wilson Electronics shall, at its option, either repair or replace the product. Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer if located within the continental U.S.
