Chore-Time Hyflo Assembly Manual page 2

Attaching the Housing Panels
The Side Housing Panels can be distinguished from each other by the position of the Screen Clip Slot and
mounting hole in the front of each Housing Panel (Right Panel Shown, See Figure below). Line up the Pre-
drilled holes in the Side Housing Panels with the holes in the Shroud and attach them with four 1/4 x 1/2"
Hex Washer Head Screws (Item 4). Attach the Left Side Housing Panel the same way..
3 4
Attach the Top Housing Panel to the Shroud using the pre-drilled holes with four 1/4 x 1/2" Washer Head
Screws. The Top Housing Panel should overlap the Side Housing Panels to provide water run-off. (See
Figure below)
3 3
Now that all four Housing Panels are
attached to the Shroud, Use four 1/4 x 1/2"
Hex Washer Head Screws to attach all four
Housing Panels together using the pre-
drilled holes at the four Corners. (See
Figure at right). Place the Fan Description
Decal, (Item 4), (Included in the Parts
Package) above the Danger Decal in the
bottom corner of the Fan as shown.
Item Description
1 Side Panel
2 1/4 x 1/2" Washer Head Screw
3 Bottom Housing Panel
4 Fan Description Decal
2
3 1
3 4
3 3
3 1
Item Description
3 2
1
2
3
48" and 52" Hyflo TM Un-Assembled Fans Assembly Manual
3 2
3 1
3 3
Bottom Reverse View
3 5
Item Description
1
2
3
4
5
Top Housing Panel Overlapping
Top Housing Panel
Shroud
1/4 x 1/2" Washer Head Screw
3 2
3 3
3 1 Side Housing Panel
overlapping the
Bottom
Housing Panel
Side Panel
Screen Clip Slot and Mounting Hole
Bottom Housing Panel
1/4 x 1/2" Washer Head Screw
Fan Description Decal
3 1
Side Housing Panel
Back side View
3 4
3 1
MV1756D
