FLT-04 User Manual Contents Caution Specifications Dimensional Drawing Components Assembly Setup Operation/Reset Procedure Troubleshooting... -
Page 2: Caution
Caution Warning Ensure no obstacles are in the column's path. Ensure the columns are not touching any walls. Ensure all cords Pinch Point are appropriate length to accommodate the change in Keep hands and fingers clear. height. Keep children away from electric height-adjustable lifting columns, control units, and handsets. There is a risk of injury and electric shock. -
Page 3: Specifications
Specifications Input Voltage 120 VAC, 60 Hz 24 VDC Output Voltage 25.5" Stroke Weight Capacity 700lbs (175 lbs Per Leg) Speed 1.50"/sec Height Range 23.5” - 49” (without table top) Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Powder Coat - White(RAL9016),... -
Page 4: Dimensional Drawing
Dimensional Drawing Legs 1.0" 0.5" 2.0" 3.2" 22.0" 1.7" M6X10 0.5" 6.5" 3.8" 7.0" Brackets Stand-Offs 7.1" 0.1" 1.9" 0.6" Ø0.25" 1.4" 0.1" 0.8" 1.0" 0.6" 6.4" 2.8" 1.6" 6.1" Ø0.4" 1.9" 2.8" 2.4" Ø0.20" Ø1.8" 0.1" 0.4" 5.1" 7.1" 6.5"... - Page 5 Dimensional Drawing Control Box 1.8" 0.6" 0.5" 5.8" 0.6000 Ø0.2 5.8" 10.1" Wired Remote 3.3" 1.4" 0.2" 3.4" 2.0" ˄ ˅ 5.7" 2.2"...
-
Page 6: Components
Components Glide Noise Attenuation (Pre-installed) Stand-Off VT Bracket Control Box Remote Power Cable LC Cable (59") Cable Clip Wood Screw Wood Screw Machine Screw M5x20 M5x16 M6x14 Description Stand-Off Glide (Pre-installed) VT Bracket Noise Attenuation Pad Control Box Remote Power Cable LC-Cable (59") Cable Clip Wood Screw: M5x20... -
Page 7: Assembly
Assembly STEP 1 Ensure the box and remote are placed so Lay out all the included components and hardware the wires can reach between all components to ensure you have everything listed on the parts page. Take four of the self-adhesive Noise Attenuation Pads (P5) and place them on the VT Brackets (P4) as shown. -
Page 8: Setup
Setup FLT-04 Leg FLT-04 Leg [M2,M4] [M1,M3] 110VAC FLT-04 CONTROL BOX WIRED REMOTE... - Page 9 Operation Normal Operation Using the wired remote, press and hold the 'Up' button to raise the lifting columns. To lower the lifting columns, press and hold the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the lifting columns will stop immediately.
-
Page 10: Troubleshooting
Troubleshooting Troubleshooting Guide Problem Possible Cause Corrective Action Low power mode Press any button on the remote and LED will activate. activated Remote LED is off. Disconnect and reconnect the RJ-45 remote connector. Ensure connection is Connection issue secure and cable is not damaged. Follow "Setting Limit Switches"...
