- Page 1 HDMI to HDMI Switch 2 input - 10 output ID# 559 Operation Manual...
- Page 2 Introduction HDMI to HDMI Switch 2 input - 10 output is the most advanced solution to HDMI signal distribution. This product is compatible to HDMI v1.3 specifications, a cutting-age technology which defines the support to transfer Deep Color (10-bit and 12-bit ) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz (6.75Gbps).
- Page 3 selected HDMI input source is originally from a DVI output. 4 HDCP Indicator: The LED will illuminate when the selected HDMI input source is HDCP-protected. 5 SYNC Indicator: The LED will illuminate when the selected HDMI IN connects to an HDMI or DVI output correctly. 6 HDMI output Indicator: The LED will illuminate when the output sources are been connected.
- Page 4 RS-232 Remote Control Protocol RS-232 modem * The connection between Splitter and remote controller with cable. Specifications Frequency bandwidth 2.25Gbps (single link) Input ports 2 x HDMI female port (Type A connector) Output port 10 x HDMI female port Power Supply 5VDC/6A (US/EU standards, CE/FCC/UL certified) Remote Control...
