- Page 1 HDMI 8x8 Matrix with HDMI and Twin CAT6 Output - ID# 15131 Operation Manual...
- Page 2 Introduction The 8×8 HDMI Matrix with simultaneous CAT6 and HDMI outputs connects eight HDMI sources to 16 displays. This matrix features 8 HDMI outputs and each HDMI output is mirrored to provide a Dual-CAT-Cable output which runs simultaneously. Connect an ID# Receiver to each of the Dual-CAT- Cable outputs to extend the HDMI signal up to 45m for multi-room connectivity.This matrix switcher can be controlled via the supplied IR...
- Page 3 System Requirements HDMI equipped source devices, connect with HDMI cables or DVI • equipped source, connect with DVI to HDMI cables HDMI equipped displays (TVs or monitors) or HDMI equipped AV • receivers, connect with HDMI cables HDMI over dual CAT6 Receiver(s) with industry CAT6 cable •...
- Page 4 Back Panel 1 CONTROL: This port is the link for Telnet or Web GUI controls, connect to an active Ethernet link with an RJ45 terminated cable (for further details, please refer to section Telnet Control & Web GUI Control). Warning: Please do not connect this port directly to the PC/Laptop as the Telnet function will not work.
- Page 5 Side Panel Ventilator: 1. Fan These are air ventilation areas, DO NOT block these areas or cover it with any object. Please allow adequate space around the unit for air circulation Remote Control Power: Press this button to switch on the device or set it to standby mode.
- Page 6 RS-232 Protocols #ID 15120 Remote Control Console Assignment Assignment ► ◄ Baud Rate: 19200bps Parity: None Stop Bit: 1 Data bit: 8 bits Flow Control: None RS-232 & Telnet Commands Command Description A1~A8 Switch Output A to 1~8 B1~B8 Switch Output B to 1~8 C1~C8 Switch Output C to 1~8 D1~D8...
- Page 7 version System Reset to A1, B2, C3 etc Setting EDID MODE. 1-STD 2-TV Display all the available commands Quit Exit (for telnet only) Note: All the commands will not be executed unless followed with a carriage return. All letters are not case-insensitive. Telnet Control Before attempting to use the Telnet control, ensure that both the Matrix (via the LAN/Control port) and the PC/Laptop or control system being used are...
- Page 8 Note: The IP address of the Matrix can be displayed on the device's LCM monitor by pressing the Menu button twice. Type 'HELP' to list the available commands (see below for reference). Type 'IPCONFIG' To show all IP configurations. To reset the IP, type 'RSTIP' and to use a set static IP, type 'SETIP'.
- Page 9 Web GUI Control On a PC/Laptop that is connected to the same active network as the Matrix, open a web browser and type device's IP address on the web address entry bar. The browser will display the device's status, control and User setting pages.
- Page 10 the Web GUI control will also need to be changed accordingly on the web address entry bar. Specifications Video Bandwidth 225 MHz/6.75 Gbps Input Ports 8×HDMI, 1×IR Extender, 1×RS-232, \ 1×RJ-45 (Control), 1×Mini USB Type B (For firmware updated only) Output Ports 8×CAT5e/6/7, 8×IR Blaster , 8xHDMI HDMI Input Cable Distance 15m/8-bit, 10m/12-bit...
- Page 11 Connection Diagram...
