- Page 1 HDBaseT 4x4 HDMI Matrix over CAT5e/6/7 Cable - ID# 15121 Operation Manual...
- Page 2 Introduction The 4x4 HDMI Matrix over 4 CAT5e/6/7 with 2 HDMI outputs supports resolutions up to 1080p Full HD and 1920x1200@60Hz with multichannel digital audio from up to four high definition sources to up to four CAT5e/6/7 output and 2 HDMI synchronized with 2 CAT5e/6/7 output ports. It supports digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio.
- Page 3 Operation Controls and Functions Front Panel LCM: This monitor displays your setting information with each input and output selection. This IR window accepts the remote control signal of this device only. Power button LED: Press this button to turn on the device and the green LED will illuminate when the power is on.
- Page 4 Back Panel 1. RS-232: This slot is to connect with D-Sub 9pin cable from the PC/ NB device for RS-232 control. 2. IP CONTROL: This port is also the link for Telnet system. For non Ethernet version this port is the link for Telnet control, connect to an active Ethernet link with an RJ45 terminated cable (for details, please refer to section RS-232 &...
- Page 5 DC24V: This slot is to plug the power cord with adaptor included in the package and then connect them with AC wall outlet for power supply. Side Panel Ventilator: These are fan ventilator area, DO NOT block these area or cover it with any object. Remote Control Power: Press this button to switch on...
- Page 6 RS-232 Protocols #ID 15120 Remote Control Console Assignment Assignment ► ◄ Baud Rate: 19200bps Parity: None Stop Bit: 1 Data bit: 8 bits Flow Control: None RS-232 & Telnet Commands Command Description A1~A4 Switch output A to 1~4 B1~B4 Switch output B to 1~4 C1~C4 Switch output C to 1~4 D1~D4...
- Page 7 Note: All the commands will not be executed unless followed with a carriage return. All letters are case-insensitive. Telnet Control Before attempting to use the telnet control, please ensure that both the Matrix (via the 'LAN /CONTROL' port) and the PC/Laptop are connected to the active networks.
- Page 8 Type “IPCONFIG” To show all IP configurations. To reset the IP, type “RSTIP” and to use a set static IP, type ”SETIP” (For a full list of RS-232 & Telnet Commands above commands, see the Note: Any commands will not be executed unless followed by a carriage return.
- Page 9 Clicking on the 'User Setting' tab allows you to reset the IP configuration. The system will ask for a reboot of the device every time any of the settings are changed. The IP address needed to access the Web GUI control will also need to be changed accordingly on the web address entry bar.
- Page 10 Connection Diagram...
- Page 11 Specifications Video Bandwidth 225 MHz/6.75 Gbps Input Ports 4 x HDMI, 5 x IR Extender, 1 x Control 1 x RS-232, 1 x Mini USB B type(for firmware update only) Output Ports 4 x CAT5e/6/7, 2 x HDMI, 5 x IR Blaster Power Supply 24V/2.7A DC (US/EU standards,CE/FCC/ UL certified)
