Converters.TV CDPS-UH4H1HFS Operation Manual

4 x 1 hdmi uhd switcher with fast switching and control system
Hide thumbs

Advertisement

Quick Links

Download this manual
4 x 1 HDMI UHD Switcher with Fast
- # 15369
Switching and Control System
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the CDPS-UH4H1HFS and is the answer not in the manual?

Questions and answers

Related Manuals for Converters.TV CDPS-UH4H1HFS

Summary of Contents for Converters.TV CDPS-UH4H1HFS

  • Page 1 4 x 1 HDMI UHD Switcher with Fast - # 15369 Switching and Control System Operation Manual...
  • Page 2 Introduction This 4 by 1 HDMI UHD Switcher allows four HDMI sources to be routed to an HDMI display. The Fast Switching Technology greatly reduces the time required to swap between inputs. The Control System not only provides direct control but also indirect control interfaces for all your connected devices.

  • Page 3: Operation Controls And Functions

    Operation Controls and Front Panel Functions 1. POWER Button and LED: Press this button to switch On or set the device to standby mode. The LED will illuminate in green when the device is power On and if it is switched to standby mode the LED will turn red.
  • Page 4 These LEDs will illuminate when IN connection obtain active low DC voltage of 0~0.5V which is also when signals has been triggered. Under normal operation, the voltage is about 3.3V. Rear Panel USB: This slot is reserved for firmware update use only. CONTROL: Connect from PC/Laptop with active internet service for Telnet or WebGUI control with RJ-45 terminated cable.
  • Page 5 SPEAKER R/L: These slots are to connect with analog speakers through banana jack cables for audio signal output from HDMI or Optical. Note: These slots only support LPMC 2CH signal, other signals will be mute automatically. DC 24V: Connect the adaptor included in the package and connect to AC wall outlet for power supply.
  • Page 6 RS-232 Protocols Switch Remote Control Assignment Assignment ► ◄ Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1 Telnet & RS-232 Commands Command Name Description Description of Parameter HELP (?) Show Command List NONE HELP N Show Description Of N = COMMAND NAME...
  • Page 7 SOUNDSYS Show AMP Sound NONE System SOUNDSYS N Set AMP Sound N=0 (STEREO), 1 (MONO) System N Show AMP Volume NONE VOL N Set AMP Volume N N=0-100 Select Input N N=1-4* Display The Current IPGONFIG NONE IP Configure SIPADDR Set Ethernet IP XXX=0~255 XXX.XXX.
  • Page 8 SOURCEDET Show All Input Signal NONE SOURCEDET N1 Show Input N1 Signal N1=1-4* SINKINFO Show Output NONE Information INNAME Show Input Name NONE INNAME N1 Show Input N1 Name NONE INNAME N1 N2 Set Input N1Name N1=1-4* N2=ABCDEFGH(Max Length=8) OUTNAME Show Output Name NONE OUTNAME A N1...

  • Page 9: Macro Control

    ACTIVE WHEN TERMINAL BLOCK PORT STATUS IN RAISING OR FALLING COMSEND N N1 N2 SEND COMMAND TO >COMSEND N N1 N2 COM PORT N[LOCATION]=COM N1[PORT]=1~2 N2=COMMAND DATA COMCONF N N1 N2 DRIVER RS232 SHOW COM PORT N3 N4 N5 SETTINGS CONFIG >COMCONF N N1 N[LOCATION]=COM...
  • Page 10 Mode 1/HDMI output native. Software Application Please download the software from www.converters.tv with file name CDPS V2.000 and save it in a directory where you may use it later. Connect the HDMI UHD Switcher with Fast Switching and Control System with an active network system and open the CDPS V2.000 application from...
  • Page 11 Then user may use the IP Address to find the control device through Telnet, Web GUI or even RS-232/Hyper Terminal tools.
  • Page 12 Telnet Control To access the Telnet control in Windows 7, click on the 'Start' menu and type "cmd" in the Search field then press enter. Under Windows XP go to the 'Start' menu and click on "Run", type "cmd" with then press enter. Under Mac OS X, go to Go→Applications→Utilities→Terminal See below for reference.
  • Page 13 This will bring us into the unit which we wish to control. Type "help" to list the available commands. Note: Commands will not be executed unless followed by a carriage return. Commands are case-sensitive. If the IP is changed then the IP Address required for Telnet access will also change accordingly...

  • Page 14: Webgui Control

    WebGUI Control On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (default setting IP: 192.168.1.50 ) on the web address entry bar. A security page will appear to ask for User and Password, please key in “Admin”...
  • Page 15 Click on Audio to adjust audio format, sound system, speaker mode and volume. Click on EDID to select EDID setting on all inputs or appoint input(s)
  • Page 16 Click on Macro Settings to insert up to 16 commands into a Macro button. Click on Command Settings to edit or remove the commands up to 128 sets.
  • Page 17 Click on Network Configuration to set the device’s IP configuration. Once the changes are saved the system will reset the IP address on device automatically and user will need to re-enter the IP address to continue the WebGUI control. Click on System Settings to trigger device power or reset the settings back to default.
  • Page 18 Connection Diagram...
  • Page 19 Specifications Video Bandwidth 340 MHz/10.2 Gbps Input Ports 4×HDMI, 4×Triggers (0~15V), 1×Control (RJ- 45), 2×COM (Terminal Block), 1×RS-232 (3.5mm), 1×USB (Service only) Output Ports 1×HDMI, 1×R/L (Banana Jacks), 5×IR, 4×Replays IR Out Frequency 30~50 kHz Baud Rate Up to 115200 bps Power Supply 24 V/3.75 A DC (US/EU standards, CE/FCC/ UL certified)

  • Page 20: Audio Format

    3840x2160@24/25/30 √ √ 3840x2160@50/60 YUV420 √ √ 4096x2160@24/25/30 √ √ 4096x2160@50/60 YUV420 √ √ Supported Audio Formats AUDIO FORMAT OUTPUT (INPUT) HDMI SPEAKERS LPCM 2CH √ √ (HDMI/Optical) LPCM 5.1CH √ (HDMI) (if AUDIOFMT (2CH only) BYPASS) LPCM 7.1CH √ (HDMI) (if AUDIOFMT (2CH only)
