Summary of Contents for Converters.TV 825
- Page 1 HDMI v1.3 2in:2out Matrix Selector ID# 825 Operation Manual...
- Page 2 Introduction Thank you for purchasing the HDMI v1.3 2in:2out Matrix Selector. While HDMI products are getting more and more popular in the market people usually have more than one HDMI devices and sources in one place. The HDMI v1.3 2in:2out Matrix Selector provides the excellent solution for connecting all the devices and sources together for your convenience use, it also provides you a variety of choices on where to play your images with remote controller.
- Page 3 • High performance HDMI 1.3 Matrix of 2 (two) input and 2 (two) output with remote control for you to link with your favor HDMI devices to enjoying movies, music, or games at once. Operating Functions Controls Front Panel (1) . Remote control sensor. (2) .
- Page 4 2. W hen ED ID swit ch to T V, t he uni t wi ll d et ec t t he f irs t HDM I out pu t sourc e 's EDI D a nd rec ord in t he un it . If th e f irs t det ec te d ou tp ut sourc e is D VI i t wi ll pass to ne xt s ource , unt il l th e f irs t HDM I b een det ec te d.
- Page 5 RS-232 Protocols Pin Assignment The connection between Switcher and remote controller with RS-232 modem cable. Switcher Remote Controller Definition Definition ------> <------ Baud Rate: 9600 bps Data bit: 8 Bits Parity: None Stop Bit: 1 bit Commands COMMAND ACTION POWER 00 Power Off (standby) POWER 01 Power On...
- Page 6 Connection and Installation...
- Page 7 Specifications Frequency bandwidth 2.25Gbps (single link) Input ports 2 x HDMI female ports, Output ports 4 x HDMI female ports EDID Standard, TV/Moving Port 1 HDMI Audio output PCM2, PCM5.1, PCM7.1, Dolby5.1, DTS5.1, DD+, DTrueHD, DTS-HD HDMI Cable in 1080p 8bit (10M), 1080p 12bit (10M) HDMI Cable out 1080p 8bit (10M), 1080p 12bit (6M) Color Space...
