- Page 1 HDMI v1.3 3 by 1 Switcher - ID# 891 Operation Manual...
- Page 2 Introduction The HDMI v1.3 3 by 1 Switcher makes it easier to switch between devices without having to always disconnect them directly from our TV/Display, enter. This three input and one HDMI output switcher makes our lives easier by bringing together our favorite recreational HDMI devices. With CEC &...
- Page 3 Operation Controls and Functions Top Panel ① Input LED indicators: Press the INPUT button repeatedly to switch to your desired source and the LED will turn on to indicate which input source has been selected. Front Panel ① INPUT switch: Press the button repeatedly to switch to your desired input source.
- Page 4 Side Panel ① HDMI inputs: Connect to the HDMI output port of your source device such as a DVD/Blu Ray Player or game console. Rear Panel HDMI output: Connect to the HDMI display. ① ② USB 5V: Using a USB cable connect to the USB port of a computer or game console in order to get power.
- Page 5 Specifications Frequency Bandwidth 2.25Gbps (single link) Input Ports 3 x HDMI Female Ports (Type A Connector) Output Port 1 x HDMI Female Port (Type A Connector) Power Supply Power over mini USB ESD Protection Human body model: ± 8kV (air-gap discharge) ±...
- Page 6 Connection...
