- Page 1 4 x 1 HDMI 4K2K Switcher - ID# 15376 Operation Manual...
- Page 2 Introduction The 4 by 1 HDMI Switcher enables the switching of four HDMI sources to a single HDMI output, allowing a display or AV Receiver to select between four devices. With fast switching technology the device can greatly eliminate the time required by swapping or turning ON/OFF the connected displays.
-
Page 3: Power & Led
Operation Controls and Functions Front Panel 1. IR Window: This IR Receiver receives the remote control signal from the packaged included remote control only with IR frequency at 38kHz. 2. POWER & LED: Press this button to turn ON the device or set the device to standby mode. The LED will illuminate in green when switch to ON. -
Page 4: Pin Definition
2. HDMI OUT: Connect to HDMI TV/display or HD Amplifier for output image and or audio display. 3. SERVICE: This slot is reserved for firmware update use only. 4. CONTROL: Connect from PC/Laptop with active internet service for Telnet or WebGUI control with RJ-45 terminated cable. - Page 5 RS-232 & Telnet Commands Command Name Description Description of Parameter Power Off (Standby) NONE Power On NONE Select Input N N=1-4 IPCONFIG Display The Current IP NONE Configure SIPADDR XXX.XXX. Set Ethernet IP XXX=0~255 XXX.XXX Address SNETMASK XXX=0~255 XXX.XXX. Set Ethernet Net Mask XXX.XXX SGATEWAY Set Ethernet...
- Page 6 SINKINFO Show All Output NONE Information INNAME Show Input Name NONE INNAME N1 N2 Set Input N1 Name N1=1-4 N2=ABCDEFGH(Max Length=8) OUTNAME Show Output Name NONE OUTNAME A N1 Set HDMI Output N1=ABCDEFGH(Max Name Length=8) Show Unit Firmware NONE Version REBOOT System Reboot NONE...
- Page 7 EDID Content HDMI Output(TV) HDMI Output Display EDID 8/2D/PCM/720p Build-In EDID, Deep color/2D3D/audio/native resolution 8/2D/PCM/ Same as above AC3/720p 8/2D/PCM/1080p Same as above EDID All 8/2D/PCM/ Same as above AC3/1080p EDID 8/2D/PCM/4K2K Same as above Mode 8/2D/PCM/ Same as above AC3/4K2K 8/2D/PCM/Y420 Same as above...
- Page 8 Web GUI On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (the default statics IP is 192.168.5.88 or available from RS-232 or use the link application from note 4 in section 6.5 to find) on the web address entry bar. The browser will display the device’s Status, IO Status, Matrix Control, Settings and Network Configuration control pages for users to control Click on EDID Control for EIDID selections.
- Page 9 Click on Network Configuration to set the device’s IP configuration once the changes is saved the system will reset the IP address on the device automatically and user will need to re-enter the IP address to continue the WebGUI function...
- Page 10 Specifications Frequency bandwidth 300Mbps to 3Gbps Input Ports 4 x HDMI 1 x USB (Service only) 1 x RJ45 (Control) 1 x RS-232 1 x IR Extender Output ports 1 x HDMI Resolution 480i~1080p@50/60, 1080p@24, 4K2K (3840x2160@24/25/30, 50/60 YUV_420 & 4096x2160@24, 50/60YUV_420Hz) HDMI I/O Cable Distance 15M@8/12bit, 5M@4Kx2K...
- Page 11 Audio Format LPCM 2/5.1/7.1CH,Dolby Digital 2~5.1CH, DTS 2~5.1CH (Pass through), Dolby TrueHD and DTS-HD Master Audio HDMI input HDMI output LPCM 2CH LPCM 5.1CH LPCM 7.1CH Dolby Digital 2~5.1CH/ DTS 2~5.1CH Dolby TrueHD/ DTS-HD Master Audio DVI and HDMI Supported Resolutions Input Output 640x480@60...
- Page 12 1920x1080i@60 1920x1080p@24 1920x1080p@25 1920x1080p@30 1920x1080p@50 1920x1080p@60 1920x1200@60(RB) 3840x2160@24/25/30, 50/60 Y420 4096x2160@24/,50/60 Y420 Connection Diagram...
