- Page 1 4-in 1-out Video/SVideo Switcher w/RS232 ID # 600 Operation Manual...
- Page 2 - Support standard video sources: 480i, 576i. - Plug and play, easy to install and operate. - CVSD-41AR can be controlled either through input selection button on the front panel or using included infrared remote control. - RS-232 interface allows control from a distant device.
- Page 3 Rear Panel 1. RS-232: 9-pin D-sub female connector for connecting to your other control console for remote control. 2. CV/SV+Audio output: Use a CV/SV cable to connect to your display. Use a 1 RCA to 1 RCA video cable to your display. Use a 2 RCA to 2 RCA audio cable to your display.
- Page 4 Connection and Installation CVSD-41AR RS-232 Remote Control Protocol * The connection between CVSD-41AR and remote controller with RS-232 modem cab Pins definition of modem cable S-232 transmission format: Baud Rate : 9600 bps Data Bit : 8 Bits Parity: None...
- Page 5 Specifications...
