Summary of Contents for Converters.TV 862
- Page 1 Optical 4 in/1 out Audio Switcher ID# 862 Operation Manual...
- Page 2 Introduction The Optical 4 in/1 out Audio Switcher is designed to select 1 of 4 TOSlink optical audio sources for connection to a digital audio sound system. All optical audio signals are passed through without delay or configuration. The device has “last memory” function and IR remote control which makes the product easy to install and user friendly.
- Page 3 1 Optical In: These slots are to connect with input source equipments such as DVD/Blue-Ray player for audio input signal sending. Left Panel ① Power: Press this button to turn on the device or to set it to standby mode. The blue LED on the top panel will illuminate when the device is turn on.
- Page 4 ① DC 5V: This slot is where you plug the 5V DC power supply into the unit and connect the adapter to an AC wall outlet. Connection and Installation...
- Page 5 Specifications Input Ports 4 x Optical Sample Frequency Up to 192 kHz Output Port 1 x Optical Audio Format PCM2, AC3/5.1, Dolby 5.1 & DTS 5.1 pass through Power Supply 5V / 1A DC ( US/EU standards, CE/FCC/UL certified) ESD Protection Human body model: ±...
