Measurement Computing PC-CARD-DAC08 User Manual page 15

Connector and Pin Out
Connector Type:
Connector Compatibility:
Main Connector:
PIN
1 GND
2 DIGITAL I/O 0
3 DIGITAL I/O 2
4 DIGITAL I/O 4
5 DIGITAL I/O 6
6 PC +5V OUT
7 GND
8 GND
9 GND
10 GND
11 GND
12 GND
13 GND
PC-CARD-C37F/26 User Connections on 37D:
PIN
1 GND
2 EXTERNAL INTERRUPT IN
3 GND
4 DIGITAL I/O 0
5 DIGITAL I/O 1
6 DIGITAL I/O 2
7 DIGITAL I/O 3
8 DIGITAL I/O 4
9 DIGITAL I/O 5
10 DIGITAL I/O 6
11 DIGITAL I/O 7
12 GND
13 GND
14 PC +5V OUT
15 GND
16 GND
17 GND
18 D/A OUT 0
19 GND
NOTE: Pins 19, 21, 23, 25, 27, 31, and 33 connected to pin 1 inside 37D housing.
SIGNAL NAME
SIGNAL NAME
Honda 26-Pin mini D-type
Translates to 37D pinout using
PC-CARD-C37F/26 cable.
PIN
14 EXT. INTERRUPT IN
15 DIGITAL I/O 1
16 DIGITAL I/O 3
17 DIGITAL I/O 5
18 DIGITAL I/O 7
19 D/A OUT 0
20 D/A OUT 1
21 D/A OUT 2
22 D/A OUT 3
23 D/A OUT 4
24 D/A OUT 5
25 D/A OUT 6
26 D/A OUT 7
PIN
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
11
SIGNAL NAME
SIGNAL NAME
D/A OUT 1
GND
D/A OUT 2
GND
D/A OUT 3
GND
D/A OUT 4
GND
D/A OUT 5
GND
D/A OUT 6
GND
D/A OUT 7
GND
N/C
N/C
N/C
N/C
