Introduction
1
1
1 Introduction
1.1 Purpose of the Manual
This installation guide provides information for the quick
installation of a VLT
frequency converter.
The installation guide is intended for use by qualified
personnel. Users are assumed to be familiar with:
•
®
VLT
•
BACnet/IP technology.
•
BMS controller that is used as a master in the
system.
Read the instructions before installation and ensure that
the instructions for safe installation are observed.
®
VLT
is a registered trademark.
®
BACnet
is a registered trademark of ASHRAE.
1.2 Additional Resources
Resources available for the frequency converters and
optional equipment:
•
The relevant frequency converter operating
instructions provide the necessary information for
getting the frequency converter up and running.
•
The relevant frequency converter design guide
provides detailed information about capabilities
and functionality to design motor control
systems.
•
The relevant frequency converter programming
guide provides greater detail on working with
parameters and many application examples.
•
The VLT
provides information about installing the
BACnet/IP and troubleshooting.
•
The VLT
provides information about configuring the
system, controlling the frequency converter,
parameter access, programming, troubleshooting,
and some typical application examples.
Supplementary publications and manuals are available
from Danfoss. See vlt-drives.danfoss.com/Support/Technical-
Documentation/ for listings.
1.3 Product Overview
1.3.1 Intended Use
This installation guide relates to BACnet/IP interface.
Ordering number:
•
134B1586 (conformal coated).
2
®
BACnet/IP MCA 125 option in a VLT
frequency converter.
®
BACnet/IP MCA 125 Installation Guide
®
BACnet/IP MCA 125 Programming Guide
Danfoss A/S © 05/2016 All rights reserved.
®
VLT
BACnet/IP MCA 125
The BACnet/IP interface is designed to communicate with
any system complying with the BACnet over Ethernet or
BACnet/IP standard. BACnet/IP provides users with the
®
network protocols to deploy standard Ethernet technology
for manufacturing and building automation applications
while enabling Internet and enterprise connectivity.
®
VLT
BACnet/IP MCA 125 is intended for use with:
•
1.3.2 Items Supplied
When the fieldbus option is not factory-mounted, the
following items are supplied:
•
•
•
•
•
•
•
1.4 Approvals and Certifications
More approvals and certifications are available. For more
information, contact a local Danfoss partner.
1.5 Disposal
®
VLT
HVAC Drive FC 102
Fieldbus option
LCP cradle
Front covers (in various sizes)
Stickers
Accessories bag
Strain relief (only for A1 and A2 enclosures)
Installation guide
Do not dispose of equipment containing
electrical components together with
domestic waste.
Collect it separately in accordance with
local and currently valid legislation.
MG92K102
